Specifications
-
Mfr Part Number: BN638
-
Features:
- 80 PLUS Gold certification (up to 92% efficiency)
-
Multi-GPU support with four PCIe connectors
-
Stable LLC Synchronous Rectifier (SR) and DC-to-DC power conversion
-
Modular cables for maximum build flexibility
-
Temperature-controlled 120mm high-quality fan
-
SFX-to-ATX adapter bracket for usage with larger case sizes
-
3-year manufacturer€™s warranty
-
Power:
-
Continuous Power: 500W
-
Peak Power: 550W
-
Input:
-
Voltage: 100 ~ 240 VAC
-
Current: 10 A
-
Frequency Range: 50 ~ 60 Hz
-
Type: ATX12V v 2.4 / EPS12V v 2.92
-
Power Factor Correction: Active PFC
-
Efficiency: 80Plus Silver up to 91% @ 20~100% load
-
Fan: 120mm Silence-optimized Rifle Fan
-
Output: + 3.3V @ 20A +5V @ 20A +12V1 @ 41.7A +5VSB @ 3A -12V @ 0.3A
-
Connectors: 1x 20+4-pin ATX Main Connector 1x P4+4 CPU Connectors 4x 6+2pin GPU PCI-Express Connectors 6x 15-pin SATA Connectors 3x 4-pin PATA Connectors
-
Protection: OCP/ OVP/ UVP/ SCP/ OTP/ OPP
-
Approvals: CE CB TUV FCC cTUVus RCM ErP WEEE RoHS
-
Color: Black
-
Dimensions (WxLxD): 130.0 x 125.0 x 64.0 mm
-
Weight: 1.14 kg
