The Tenda TEG1105P-4-63W PoE Switch is engineered for small businesses, home offices, and network installers who need reliable Power over Ethernet connectivity in a compact desktop form factor. This advanced 5-port gigabit switch delivers:
-
4 PoE+ ports providing IEEE 802.3at power over ethernet for IP cameras, wireless access points, and VoIP phones
-
63W total PoE budget supporting multiple powered devices simultaneously
-
Gigabit performance across all ports for high-speed data transmission
-
Desktop design perfect for office environments and small network deployments
Key Features
-
4 x PoE+ ports supporting IEEE 802.3at/af standard with up to 30W per port
-
1 x gigabit uplink port for high-speed connection to main network
-
Plug-and-play operation requiring no configuration or management software
-
Auto-sensing PoE detection preventing damage to non-PoE devices
-
Energy-efficient design with intelligent power management
-
Compact desktop form factor with fanless silent operation
Technical Specifications
| Manufacturer |
Tenda Technology |
| Model Number |
TEG1105P-4-63W |
| Type |
5-Port Gigabit Desktop PoE Switch |
| Port Configuration |
4 x PoE+ ports, 1 x Gigabit uplink |
| PoE Standard |
IEEE 802.3at/af |
| Total PoE Budget |
63W |
| Power per Port |
Up to 30W (PoE+) |
| Switching Capacity |
10 Gbps |
| MAC Address Table |
2K entries |
| Power Consumption |
5W (without PoE load) |
| Compatible Systems |
IP cameras, wireless access points, VoIP phones, small business networks |
Target Use Cases
IP Camera Surveillance: Perfect for powering and connecting IP security cameras where the PoE switch eliminates the need for separate power adapters, simplifying installation and reducing cable requirements for comprehensive surveillance systems.
Wireless Network Expansion: Ideal for extending wireless coverage with access points where power over ethernet capability enables flexible AP placement without requiring nearby power outlets, perfect for small business and home office networks.
VoIP Phone Deployments: Excellent for office phone systems where the IEEE 802.3at standard provides reliable power and data connectivity for IP phones, conference devices, and other communication equipment.
Frequently Asked Questions
Q: What devices can be powered by this PoE switch?
A: This desktop ethernet switch can power any IEEE 802.3at/af compatible device including IP cameras, wireless access points, VoIP phones, LED lighting, and other PoE-enabled equipment requiring up to 30W per port.
Q: How does the 63W power budget work across multiple ports?
A: The 5-port switch intelligently manages power distribution across the 4 PoE ports, automatically allocating power based on device requirements up to the total 63W budget, ensuring optimal performance for all connected devices.
Q: Is this switch suitable for small business networking?
A: Yes, this gigabit desktop switch is specifically designed for small business applications, providing enterprise-grade PoE functionality in an affordable, easy-to-deploy package that requires no technical configuration or management.
Q: Does this switch require any configuration or management?
A: No, this is a true plug-and-play small business networking solution with auto-sensing capabilities that automatically detects PoE requirements and provides appropriate power levels without any manual configuration required.
Q: What safety features protect non-PoE devices?
A: The switch includes intelligent PoE detection that automatically identifies whether connected devices require power, preventing damage to standard Ethernet devices while ensuring reliable power over ethernet delivery to compatible equipment.
Tenda TEG1105P-4-63W 5-Port Gigabit Desktop PoE Switch with IEEE 802.3at, 63W power budget for IP cameras, wireless access points, and VoIP phones.
