Taoglas Ultima MA111 2in1 GPS/GLONASS/GALILEO & 3G/2G Permanent Mount Antenna, 3M RG-174
The MA.111 Ultima Series 2in1 GPS/GLONASS/GALILEO & Cellular Combination Antenna is an extremely low profile combination high performance GPS/GLONASS/GALILEO and penta-band cellular antenna solution for professional telematics applications. At only 22 mm height it is the lowest profile antenna in the market, with a diameter of 55 mm. It is designed to be mounted and couple to the metal structures it attaches to radiate. Durable UV ABS housing, thread and nut is resistant to vandalism and direct attack.
The IP67 waterproof robust plastic body makes it extremely light, economical for shipping and minimum weight impact on vehicles. This also makes it ideal for use in humid environments such as water pits or marine applications as there are no external metal parts to corrode. The closed cell foam with double-sided adhesive provides a permanent waterproof seal and can adjust to different curvatures, stopping water from leaking under the antenna into the mounting hole.
For applications that require mounting on non-metal structures we recommend the Hercules MA.105.
- Height 19.6mm (0.77")
- Diameter 55mm (2.17")
- Heavy duty screw mount
- UV and vandal resistant ABS housing and thread
- IP67 compliance
- Standard is GPS/GLONASS/GALILEO - 3M RG174 SMA(M)
- Cellular - 3M CFD200 SMA(M)
- Customizable
- ROHS Compliant
Product Type: Antenna
Environmentally Friendly: Yes
Environmental Certification: RoHS
Product Color: Black
Diameter: 2.17"
Country Of Origin: Taiwan
Brand Name: Taoglas
Form Factor: Screw Mount
Manufacturer: Taoglas
Product Model: MA111
Product Name: Ultima MA111 2in1 GPS/GLONASS/GALILEO & 3G/2G Permanent Mount Antenna, 3M RG-174
Product Line: Ultima
Application/Usage: Marine
Manufacturer Part Number: MA111.C.LB.001
Manufacturer Website Address: http://www.taoglas.com
Packaged Quantity: 1
Weight (Approximate): 7.36 oz
