APC Easy UPS 3S Parallel Maintenance Bypass Panel for 3 UPSs
The Easy UPS 3S Parallel Maintenance Bypass Panel is engineered for organizations requiring seamless maintenance operations on parallel UPS configurations. This maintenance bypass solution supports 3 UPSs in parallel topology, delivering 10-40kVA capacity at 208V, making it ideal for data centers, enterprise IT environments, and critical infrastructure requiring zero-downtime maintenance. The bypass panel enables safe equipment servicing without interrupting power delivery to connected loads, ensuring business continuity while performing essential maintenance tasks on your parallel UPS system.
Key Features
- Supports 3 UPSs in parallel configuration for redundant power delivery
- 10-40kVA capacity range accommodates mid-to-large enterprise deployments
- 208V single-phase input/output for North American installations
- Maintenance bypass functionality enables safe UPS servicing without load interruption
- Integrated with Easy UPS 3S ecosystem for simplified management
- Schneider Electric reliability and industry-leading support
- Compact design optimizes data center floor space utilization
Technical Specifications
| Specification |
Details |
| Manufacturer |
APC by Schneider Electric |
| Product Series |
Easy UPS 3S |
| Part Number |
E3SBPAR10K40F |
| UPS Configuration |
3 UPSs Parallel |
| Power Capacity |
10-40kVA |
| Input/Output Voltage |
208V |
| Function |
Maintenance Bypass Panel |
| Application |
Data Centers, Enterprise IT, Critical Infrastructure |
Frequently Asked Questions
What is a maintenance bypass panel for parallel UPS systems?
A maintenance bypass panel allows you to safely service or replace UPS units in a parallel configuration without interrupting power to your critical loads. It automatically transfers the load to the bypass source during maintenance windows, ensuring zero downtime.
How many UPSs can this parallel maintenance bypass panel support?
The E3SBPAR10K40F is specifically designed to support 3 UPSs in parallel, providing redundancy and load-sharing capabilities for enterprise-grade power protection.
Is this bypass panel compatible with other UPS models?
This panel is engineered for the Easy UPS 3S product line. Compatibility should be verified with your specific UPS models and Schneider Electric technical documentation before installation.
What voltage configuration does this maintenance bypass panel support?
The E3SBPAR10K40F operates at 208V, making it suitable for standard North American three-phase power environments commonly found in data centers and enterprise facilities.
