ASUS ESC8000A-E12P AMD EPYC 9004 4U GPU Server
The ASUS ESC8000A-E12P is a high-performance 4U GPU server engineered for organizations demanding extreme compute power for AI, machine learning, and HPC workloads. This dual-processor AMD EPYC 9004 server supports up to eight dual-slot GPUs with PCIe 5.0 connectivity, making it ideal for data centers, research institutions, and enterprises running GPU-accelerated applications. With 24 DDR5 DIMM slots, 13 PCIe 5.0 slots, and eight NVMe bays, this system delivers the bandwidth and scalability needed for next-generation AI infrastructure and scientific computing.
Key Features
- Supports up to eight dual-slot GPUs for massive parallel processing
- Dual AMD EPYC 9004 processors for exceptional multi-threaded performance
- PCIe 5.0 switch solution with 13 PCIe 5.0 slots for ultra-fast GPU interconnect
- Up to 24 DDR5 DIMM slots for high-bandwidth memory expansion
- Eight NVMe drive bays for fast storage and data access
- Four 3000W Titanium redundant power supplies for reliability
- Independent CPU and GPU airflow tunnels for optimized thermal management
- Optional OCP 3.0 networking for enterprise connectivity
- ASUS ASMB11-iKVM remote management for out-of-band administration
- ASUS Control Center IT management software with hardware-level security
Technical Specifications
| Specification |
Details |
| Manufacturer |
ASUS |
| Model |
ESC8000A-E12P |
| Form Factor |
4U Rackmount |
| Processors |
Dual AMD EPYC 9004 Series |
| GPU Support |
Up to 8 dual-slot GPUs |
| Memory |
Up to 24 DDR5 DIMM slots |
| PCIe Slots |
13 PCIe 5.0 slots with switch solution |
| Storage |
8 NVMe drive bays |
| Power Supply |
4x 3000W Titanium redundant PSUs |
| Networking |
OCP 3.0 optional |
| Remote Management |
ASUS ASMB11-iKVM |
| Management Software |
ASUS Control Center IT with security features |
| Cooling |
Independent CPU and GPU airflow tunnels |
Frequently Asked Questions
What is the ASUS ESC8000A-E12P best used for?
The ASUS ESC8000A-E12P is optimized for AI training, deep learning inference, HPC simulations, and data analytics workloads requiring multiple high-performance GPUs and extreme memory bandwidth.
How many GPUs can this 4U GPU server support?
This dual-processor server supports up to eight dual-slot GPUs, providing exceptional GPU density for GPU-accelerated computing and AI applications.
What are the power requirements for the ESC8000A-E12P?
The system includes four 3000W Titanium redundant power supplies, delivering up to 12,000W total capacity with high efficiency and reliability for demanding enterprise deployments.
Does this server support PCIe 5.0?
Yes, the ESC8000A-E12P features a PCIe 5.0 switch solution with 13 PCIe 5.0 slots, enabling ultra-fast GPU interconnect and maximum bandwidth for GPU-to-GPU communication.
