BCDVideo NVRBCD-24 All-in-One Network Video Recorder
The NVRBCD-24 is a powerful all-in-one network video recorder designed for organizations requiring integrated surveillance infrastructure with minimal hardware footprint. This 1U appliance combines a 24-port PoE+ managed switch with enterprise-grade video recording capabilities, making it ideal for mid-to-large deployments where space and power efficiency matter. Powered by an Intel 7th Gen Core i7-7700 processor, the NVRBCD-24 delivers reliable performance for continuous video surveillance while managing network connectivity through a single integrated device. With support for up to 80TB of raw storage and swappable HDD bays, this network video recorder scales to your security needs without requiring separate switch infrastructure.
Key Features
- 24-port PoE+ to PoE managed switch integrated into single 1U chassis
- Intel 7th Gen Core i7-7700 processor for reliable video processing
- Up to 80TB raw storage capacity with four swappable 3.5" HDD bays
- Web-based management UI for switch configuration and PoE settings
- TPM 2.0 security module for secure edge deployments
- PoE management software included for power monitoring and control
- Two-year hardware warranty with five-year Keep Your Hard Drive warranty
- Consolidated network and recording infrastructure reduces deployment complexity
Technical Specifications
| Specification |
Details |
| Manufacturer |
BCDVIDEO |
| Part Number |
NVRBCD-24-32T-8 |
| Form Factor |
1U Rackmount |
| Processor |
Intel Core i7-7700 (7th Generation) |
| Network Switch |
24-port PoE+ to PoE managed switch |
| Storage Capacity |
Up to 80TB raw storage |
| HDD Bays |
Four swappable 3.5" bays |
| Security |
TPM 2.0 |
| Management Interface |
Web-based UI |
| Warranty |
2-year hardware + 5-year drive warranty |
Frequently Asked Questions
What is an all-in-one network video recorder?
An all-in-one network video recorder combines video surveillance recording capabilities with network switching infrastructure in a single appliance. The NVRBCD-24 integrates a 24-port PoE+ switch with NVR functionality, eliminating the need for separate devices and reducing deployment complexity in security installations.
How much video storage does the NVRBCD-24 support?
The NVRBCD-24 supports up to 80TB of raw storage capacity through four swappable 3.5" hard drive bays. This allows organizations to scale storage based on retention requirements and camera count without replacing the entire appliance.
Can the NVRBCD-24 manage PoE power distribution?
Yes, the integrated 24-port PoE+ managed switch provides power over Ethernet to connected IP cameras and devices. The included PoE management software allows administrators to monitor and control power delivery to individual ports through the web-based management interface.
Is the NVRBCD-24 suitable for enterprise surveillance deployments?
The NVRBCD-24 is designed for mid-to-large enterprise environments requiring integrated network video recorder and switch functionality. With an Intel Core i7-7700 processor, TPM 2.0 security, and scalable 80TB storage, it provides enterprise-grade performance for continuous surveillance operations.
