The Black Box ACX2MR-DPHS-SM is a professional-grade KVM extender receiver designed for organizations requiring high-performance video and peripheral extension over extended distances. This modular receiver card delivers 4K30 DisplayPort 1.1 video quality with integrated USB-HID support for seamless keyboard and mouse control. Built for the DKM FX modular chassis platform, it enables flexible KVM matrix switching in broadcast, medical imaging, financial trading, and mission-critical control room environments where reliable, scalable video extension is essential.
Key Features
- Single-monitor 4K30 DisplayPort 1.1 video output with crystal-clear resolution
- Modular design integrates into DKM FX chassis for scalable KVM matrix configurations
- USB-HID keyboard and mouse extension for complete peripheral control
- High-performance fiber-based transmission for extended distance connectivity
- Professional-grade reliability for 24/7 control room and broadcast applications
- Hot-swappable receiver module for flexible system expansion
Technical Specifications
| Specification |
Details |
| Manufacturer |
BLACK BOX |
| Part Number |
ACX2MR-DPHS-SM |
| Product Type |
Modular KVM Extender Receiver |
| Video Interface |
DisplayPort 1.1 |
| Maximum Resolution |
4K30 (3840 x 2160 @ 30Hz) |
| Monitor Support |
Single-monitor configuration |
| Peripheral Support |
USB-HID (keyboard, mouse) |
| Transmission Medium |
Fiber optic |
| Platform |
DKM FX modular chassis |
| Form Factor |
Hot-swappable receiver card module |
Frequently Asked Questions
What is a KVM extender receiver and how does it work?
A KVM extender receiver is a device that receives video, keyboard, and mouse signals transmitted over fiber optic cables from a remote transmitter. The Black Box ACX2MR-DPHS-SM receives DisplayPort 1.1 video at 4K30 resolution and USB-HID peripheral data, allowing operators to control computers from extended distances without signal degradation.
Can I use this receiver with non-DKM systems?
The ACX2MR-DPHS-SM is specifically designed as a modular receiver card for the DKM FX chassis platform. It requires integration into a compatible DKM modular system to function. Consult Black Box documentation or contact technical support for compatibility verification with your existing infrastructure.
What are the distance limitations for this DisplayPort 1.1 KVM extender?
Fiber optic transmission enables extended distance connectivity far beyond standard copper cables. Exact distance specifications depend on your complete system configuration, transmitter model, and fiber type. Contact Black Box for detailed distance ratings for your specific deployment scenario.
Is this receiver suitable for 4K60 video applications?
The ACX2MR-DPHS-SM supports DisplayPort 1.1 at 4K30 resolution maximum. For 4K60 applications, you would need a higher-specification receiver model. Verify your resolution requirements before purchasing to ensure this receiver meets your performance needs.
