Celona Omni-directional Antenna with 13 dBi Gain for Private 5G Networks
The Celona CN-ANT-OMNI-KIT is a professional-grade omni-directional antenna engineered for enterprises deploying private cellular networks across large outdoor areas. This dual-port antenna system provides 360° coverage with consistent signal strength, making it ideal for industrial campuses, logistics hubs, and mission-critical wireless deployments. With 13 dBi gain and support for both horizontal and vertical polarization, this Celona Certified Antenna Portfolio component ensures reliable Sub-6 GHz 5G and LTE connectivity for outdoor access points requiring extended range and uniform coverage patterns.
Key Features
- 360° omni-directional coverage for seamless outdoor network deployment
-
13 dBi gain for extended range and improved signal strength
- Dual N-type connectors (2-port design) for redundancy and flexible mounting
- Operates across 3300–3800 MHz frequency band for Sub-6 GHz 5G/LTE support
- Horizontal and vertical polarization support for consistent performance
- Part of Celona Certified Antenna Portfolio for guaranteed compatibility
- Optimized for large-area outdoor deployments and enterprise-scale networks
- Weather-resistant design suitable for harsh industrial environments
Technical Specifications
| Specification |
Details |
| Manufacturer |
Celona |
| Part Number |
CN-ANT-OMNI-KIT |
| Antenna Type |
Omni-directional |
| Frequency Range |
3300–3800 MHz (Sub-6 GHz) |
| Gain |
13 dBi |
| Connectors |
2x N-type (Female) |
| Polarization |
Horizontal and Vertical |
| Coverage Pattern |
360° Omni-directional |
| Certification |
Celona Certified Antenna Portfolio |
| Application |
Outdoor Access Points for Private Cellular Networks |
Frequently Asked Questions
What is an omni-directional antenna and why do I need it?
An omni-directional antenna radiates signal uniformly in all horizontal directions (360°), making it perfect for outdoor deployments where coverage needs to reach multiple directions simultaneously. Unlike directional antennas, omni-directional designs eliminate coverage dead zones and are ideal for private 5G networks serving large campuses or industrial areas.
What does 13 dBi gain mean for my network performance?
The 13 dBi gain specification indicates the antenna's ability to amplify and focus radio signals, extending transmission range and improving signal strength compared to standard antennas. This higher gain ensures reliable connectivity across larger outdoor areas while maintaining consistent performance for Sub-6 GHz 5G and LTE applications.
Is the Celona CN-ANT-OMNI-KIT compatible with my outdoor access point?
Yes, the CN-ANT-OMNI-KIT is specifically designed for Celona outdoor access points and is part of the Celona Certified Antenna Portfolio, ensuring full compatibility and optimized performance. The dual N-type connectors support standard mounting configurations for most enterprise outdoor AP installations.
Can this antenna support both 5G and LTE networks?
Absolutely. The Celona omni-directional antenna operates across the 3300–3800 MHz frequency band and supports both Sub-6 GHz 5G and LTE connectivity, making it versatile for hybrid network deployments or phased 5G rollouts on private cellular networks.
