ComNet Bi-Directional Contact Closure Transceiver
The ComNet™ FDC10 Series bi-directional contact closure transceiver provides bi-directional transmission of contact closure over one multimode or single mode optical fiber. The transceiver has a contact input and a 0.5 amp contact output. The bi-directional contact closure module has two relay outputs and one relay input. One relay output follows the "relay input" at the remote end. When the remote "relay input" is shorted, the local relay output is closed and vice-versa. The second relay output is closed when "carrier" is detected from the remote end, this indicates that the optical fiber is connected and that the remote end has power and is operating.
- FDC10(M,S)1(A,B) models are housed in a smaller-sized package for stand-alone mounting only, for use in those applications where space may be limited
- Voltage transient protection on all power and signal input/output lines provides protection from power surges and other voltage transient events.
- Automatic resettable solid-state current limiters
- Relay contact for Carrier Detect (normally closed with carrier present)
- Plug-and-play design ensures ease of installation requiring no electrical or optical adjustments.
- Designed to meet full compliance with the environmental requirements (ambient operating temperature, mechanical shock, vibration, humidity with condensation, high-line/lowline voltage conditions and transient voltage protection) of NEMA TS-1/TS-2 and the Caltrans Specification for Traffic Signal Control Equipment.
- Point-to-Point transmission architecture
- Distances up to 69 km (43 miles)
- 30 VDC, 0.5 amp relay output, normally open
- Transmits a single contact closure in one or two directions
Product Type: Transceiver/Media Converter
Environmentally Friendly: Yes
Environmental Certification: WEEE
Country Of Origin: United States
Product Series: FDC10
Brand Name: ComNet
Form Factor: Surface-mountable
Manufacturer: ACRE
Product Name: Bi-Directional Contact Closure Transceiver
Manufacturer Part Number: FDC10M1A
Manufacturer Website Address: http://www.acre-co.com
Package Contents:
- Bi-Directional Contact Closure Transceiver
- DC Plug-in Power Supply, 90-264 VAC, 50/60 Hz
Limited Warranty: Lifetime
