ComNet FVR10D1ES - Video/serial/network extender - 100Mb LAN - up to 29.8 miles - 1310 nm / 1550 nm
- 10-bit digital video transmission
- One bi-directional data channel
- One 10/100 BASE-T/TX fast Ethernet port
- IEEE 802.3 compliant
- Automatic MDI/MDI-X crossover
- Exceeds all requirements for RS-250C short-haul transmission: true broadcast video performance
- Compatible with all NTSC, PAL, or SECAM CCTV camera systems
- Certified to the requirements of NEMA TS-1/TS-2 and the Caltrans Specification for Traffic Signal Control Equipment
- Voltage transient protection on all power and signal input/output lines provides unconditional protection from power surges and other voltage transient events
- Automatic resettable fuses on all power lines
- Distances up to 30 miles (48 km)
- Bi-color (Red/Green) LED status indicators provide rapid indication of critical operating parameters
The ComNet FVT/FVR10D1E series video transmitter/receiver and data transceiver supports the simultaneous transmission of short haul quality 10-bit EIA RS-250C digital video with one bi-directional data channel plus one 10/100 Mbps fast Ethernet port. The modules are universally compatible with major CCTV camera manufacturers and supports RS232, RS422 and 2 or 4-wire RS485 data interfaces and most data protocols. It also supports "up-the-coax" data transmission from most major manufacturers. Packaged in the exclusive ComNet ComFit housing, the FVT/ FVR10D1E units may be either wall or rack-mounted, or may be DIN-rail mounted by the addition of ComNet model DINBKT1 adaptor plate.
-
Robust performance
Designed to operate in extreme conditions, the FVR10D1ES thrives in environments with temperatures ranging from -40°C to 75°C and humidity levels of 0 - 95% (non-condensing), ensuring reliable performance where lesser devices fail.
-
Versatile connectivity
With a comprehensive suite of interfaces including RS-232/422/485, network, and video connections, this device offers flexible integration options for a wide range of applications.
-
Extended reach
The FVR10D1ES can transmit data over distances up to 48 km, facilitated by its ST single-mode fiber optic interface, making it an ideal solution for extended network configurations.
-
Durable design
Compliant with NEMA TS-1 and TS-2 standards, this device is built to withstand the rigors of outdoor and traffic-related applications, ensuring a long service life with an MTBF of 100,000 hours.
