Geist Switched Unit Level Monitoring MNS5MGB1-24PJ48-3TL6A0A10-S - Power distribution unit (rack-mountable) - AC 208 V - 4.9 kW - RS-232, USB, Ethernet 10/100/1000 - input: NEMA L6-30P - output connectors: 24 (4 x IEC 60320 C19, 20 x IEC 60320 C13) - 0U - 10 ft cord - black powder coat - TAA Compliant
-
Efficient power distribution
The Geist Switched Unit Level Monitoring power distribution unit ensures efficient distribution of power across 24 output connectors, including 20 x power IEC 60320 C13 and 4 x power IEC 60320 C19, catering to a wide range of power needs in a compact, rack-mountable form factor.
-
Advanced remote management
Equipped with Ethernet 10/100/1000, RS-232, and USB interfaces, this unit supports a comprehensive suite of remote management protocols including SNMP, HTTP, and HTTPS, enabling seamless integration and management within any network infrastructure.
-
Comprehensive circuit protection
Featuring 2 x 20A double pole magnetic breakers and a circuit/breaker current monitoring system, the unit provides robust protection against overloads, ensuring reliable power distribution and safeguarding connected equipment.
The Vertiv Geist Switched RPDU VP5N30AU is a 30A, 208V, 0U vertical rack power distribution unit with input power monitoring and outlet level switching. It has (20) U-Lock C13 and (4) U-Lock C19 receptacles and a NEMA L6-30P plug providing 4.9kW of power capacity. This device allows you to remotely turn off receptacles to avoid accidental overloads and power cycle equipment to reboot unresponsive critical IT equipment. It is integrated with the Vertiv Geist Next-Generation IMD which displays power data via its 128x128 high-visibility LCD. It has an internal sensor that intelligently adjusts the orientation based on horizontal or vertical installation. This includes a redundant power-sharing port that connects two IMDs in the rack and provides backup power in case of power loss. Enhanced security with a secure boot is added to the device to help ensure data and operations are protected. The units are UL-listed, TAA-compliant, RoHS certified, and individually tested for functionality and reliability.
- Switched Rack PDU allows remote rebooting of outlets to power cycle unresponsive IT equipment
- VP5N30AU is a rack mount PDU with 20 U-Lock C13 and 4 U-Lock C19 receptacles and NEMA L6-30P plug
- Vertiv Geist Next-Generation IMD has a 128x128 high-contrast LCD for monitoring data
- Helps ensure that data and operations are protected with the enhanced security features
- Vertiv Geist rPDUs are individually tested, UL-Listed, TAA-Compliant, and RoHS certified
