StarTech.com HDMI over CAT5e or CAT6 HDBaseT Extender with USB Hub and IR - 295 ft (90m) - Up to 4K
This HDMIextenderkit uses HDBaseT 2.0 technology, enablingyou to extend4K HDMI video and four USB 2.0 peripheral devicesto a remote locationup to 295 feet (90 meters) away, usinga single CAT5e or CAT6 cable. The extender canextend 1080p(HD)video evenfurther atup to330 feet (100 meters).
You can power both the transmitter and receiver using the same single power source, which you can connect to either the extender or receiver using Power Over Cable (POC). You can also connect up to four USB devices on the remote side andsupport3D video and7.1 digital audio. The versatility of this video extender makes it the perfect solution for digital signage applications in large buildings such as commercial shopping centers, stadiums, schools, and hospitals.
What is HDBaseT?
HDBaseT is a standardized, zero-latency video technology that's revolutionizing HDMI distribution. HDBaseT uses an advanced method of modulation that enables you to distribute uncompressed HDMI audio and video along with additional signals such as USB and power over cable.
Extend more with HDBaseT
The extender offers a complete end-to-end solution, using HDBaseT technology to extendHDMI, IR, power and USB over a single CAT5e cable. With power and USB along with your video signal,HDBaseT is the clear choice for every integrator and system designer. The added benefit of power over cable means that you'll only need one power source at one side of your extension, and USB lets you add a console at the remote location-great for extending video and control to areas where power outlets may be limited, such as industrial sites.
Astonishing 4K picture quality from an impressive distance
The A/V industry is quickly adopting 4K as the new high-resolution video standard. But long-range video distribution can be a challenge if you're using standard HDMI cablesbecause the signal becomes susceptible to degradation at 30 feet.HDBaseT maintains your Ultra HD 4K picture quality - four times the resolution of high-definition 1080p - even at 330 feet away from your video source. Plus, because the extender supports high-definition 1080p and lower resolutions, you can comfortably use this extender to make any video source lookgreat,while future proofing your setup for 4K implementation.
Simplify your setup
This extender has been specifically designed for a simple and tidy installation. HDBaseT technology offers single-cable installation, so you can integrate it seamlessly using your existing CAT5e or CAT6 infrastructure. This means that you can avoid the hassle of running multiple Ethernet cables, while reducing potential failure points.
The extender also features Power-over-Cable technology, so youonly need one power source for both the extender and receiver units.Mounting hardware is includedfor both the extender and receiver, for discreet, professional installation.
The ST121HDBTU is TAA compliant is backed by a 2-year StarTech.com warranty with free lifetime technical support.
HDBaseT is a registered trademark ofThe HDBaseT Alliance.
More from the Manufacturer
- Supports Dolby? TrueHD?, DTS-HD Master Audio?
- No software or drivers required
- Also supports HD video resolutions such as 1920x1200 or 1080p at 330 ft
- Mounting brackets are included for a hassle-free installation
- Maintain astonishing picture quality up to 295 feet away, with support for UltraHD 4K
- Extend video to locations where power outlets are limited, with both the transmitter and receiver using a single power source at either side of the connection
Product Type: Video Extender Transmitter/Receiver
Environmentally Friendly: Yes
Environmental Certification: WEEE
Transmitter Height: 0.90"
Transmitter Width: 3"
Transmitter Depth: 4"
Receiver Height: 0.90"
Receiver Width: 3"
Receiver Depth: 4"
Transmitter Weight (Approximate): 10.79 oz
Receiver Weight (Approximate): 10.79 oz
Taa Compliant: Yes
Country Of Origin: Taiwan
Brand Name: StarTech.com
Form Factor: Desktop
Manufacturer: StarTech.com
Product Name: HDMI over CAT5 HDBaseT Extender with USB Hub - 295 ft (90m) - Up to 4K
Manufacturer Part Number: ST121HDBTU
Manufacturer Website Address: http://www.startech.com
Package Contents:
- 1 x HDMI over CAT6 transmitter
- 1 x HDMI over CAT6 receiver
- 1 x IR blaster
- 1 x IR receiver
- 1 x USB cable
- 2 x Foot pad sets
- 2 x Power adapters
- 2 x Mounting brackets
- 1 x Quick install guide
Limited Warranty: 2 Year
