HighPoint RocketAIC 7505HW 4TB NVMe AIC SSD
The RocketAIC 7505HW NVMe AIC SSD is engineered for data center professionals, content creators, and enterprise IT teams who demand extreme storage performance. This PCI-Express 4.0 x16 add-in card integrates four Samsung 990 PRO M.2 NVMe SSDs into a single, pre-configured solution delivering up to 27,000 MB/s sequential transfer speeds. Perfect for high-throughput applications, virtualization environments, and mission-critical workloads requiring maximum IOPS and bandwidth, the RocketAIC 7505HW eliminates configuration complexity while maximizing your storage infrastructure's performance potential.
Key Features
- Four integrated Samsung 990 PRO M.2 NVMe SSDs (1TB each) for 4TB total capacity
- PCIe 4.0 x16 interface delivering up to 27,000 MB/s sequential performance
- Four dedicated PCIe 4.0 x4 M.2 ports for independent drive management
- Full-height, full-length form factor compatible with standard server and workstation slots
- 2400TB total TBW (Terabytes Written) endurance rating across all drives
- Pre-configured and ready to deploy—no additional setup required
- 3-year manufacturer warranty for enterprise-grade reliability
Technical Specifications
| Specification |
Details |
| Manufacturer |
HighPoint Technologies |
| Part Number |
RA7505HW-A04T0-0D |
| Product Series |
RocketAIC 7505HW |
| Total Storage Capacity |
4TB (four 1TB Samsung 990 PRO drives) |
| Interface |
PCI-Express 4.0 x16 |
| M.2 Ports |
Four PCIe 4.0 x4 ports |
| Sequential Read Speed |
Up to 27,000 MB/s |
| Form Factor |
Full-height, full-length add-in card |
| Endurance Rating |
2400TB TBW total |
| Warranty |
3 years |
Frequently Asked Questions
What is an NVMe AIC SSD and how does it improve performance?
An NVMe AIC SSD (add-in card) combines multiple M.2 NVMe drives on a single PCIe card, enabling parallel data access and dramatically higher throughput than traditional single-drive solutions. The RocketAIC 7505HW's four-drive configuration achieves up to 27,000 MB/s—ideal for applications requiring sustained, high-speed data transfers.
Is the RocketAIC 7505HW compatible with my server or workstation?
Yes, the RocketAIC 7505HW is compatible with any system featuring a standard PCIe x16 slot. Its full-height, full-length design fits most enterprise servers, workstations, and high-performance computing platforms. Verify your system's PCIe slot availability and BIOS support for NVMe add-in cards before installation.
What makes Samsung 990 PRO drives ideal for this NVMe AIC SSD?
Samsung 990 PRO M.2 NVMe SSDs are enterprise-grade drives offering exceptional reliability, high IOPS, and sustained performance under heavy workloads. Pre-integrated into the RocketAIC 7505HW, they eliminate compatibility concerns and deliver consistent, predictable performance for data centers and mission-critical applications.
How long will the RocketAIC 7505HW last with the 2400TB TBW endurance rating?
The 2400TB TBW (Terabytes Written) endurance rating represents the total write capacity across all four drives combined. For typical enterprise workloads writing 100TB annually, this translates to approximately 24 years of service life, ensuring long-term reliability and cost-effectiveness.
