i-PRO WJ-NX400 Network Disk Recorder
The WJ-NX400 network disk recorder is purpose-built for enterprise-scale IP video surveillance deployments requiring high-throughput, reliable recording across 64 camera channels. This embedded network disk recorder eliminates the need for dedicated PC infrastructure, delivering PC-less operation with integrated GUI for immediate deployment. Ideal for large facilities, government agencies, and security integrators managing complex surveillance systems, the WJ-NX400 combines H.265/H.264 codec support with scalable architecture to grow from 64 to 128 channels as your security needs expand.
Key Features
- 64-channel expandable to 128-channel capacity with H.265/H.264 codec support
- 640 Mbps total throughput for high-bandwidth simultaneous recording
- Integrated GUI for PC-less operation and system administration
- Multiple RAID configurations for data redundancy and storage reliability
- Embedded IP security architecture with robust access controls
- One-box appliance for viewing, recording, and alarm management
- Scalable design for large-scale surveillance deployments
- Secure high-bandwidth recording with enterprise-grade performance
Technical Specifications
| Specification |
Details |
| Manufacturer |
I-PRO AMERICAS INC. |
| Part Number |
WJ-NX400/27000T3 |
| Product Type |
Network Disk Recorder (NVR) |
| Camera Channels |
64 channels (expandable to 128) |
| Video Codec Support |
H.265, H.264 |
| Total Throughput |
640 Mbps |
| Storage Configuration |
Multiple RAID options supported |
| Operation Mode |
Embedded, PC-less with integrated GUI |
| Security Features |
Embedded IP security, access controls |
| Functions |
Recording, viewing, alarm management, system administration |
| Deployment Scale |
Large-scale surveillance systems |
Frequently Asked Questions
What is a network disk recorder and how does it differ from traditional NVRs?
A network disk recorder like the WJ-NX400 is a specialized NVR appliance that combines recording, storage, and management in a single embedded unit. Unlike traditional solutions requiring separate PC infrastructure, this recorder operates independently with an integrated GUI, reducing complexity and deployment time for large surveillance systems.
Can the WJ-NX400 handle 64 camera channels simultaneously?
Yes, the WJ-NX400 is designed to support 64 camera channels with 640 Mbps total throughput, enabling simultaneous high-bandwidth recording across all channels. The system is also expandable to 128 channels for growing security deployments.
What video codecs does the WJ-NX400 network disk recorder support?
The WJ-NX400 supports both H.265 and H.264 video codecs, providing flexibility in camera compatibility and allowing you to optimize storage efficiency with modern H.265 compression while maintaining backward compatibility with H.264 systems.
How does RAID configuration improve reliability on this embedded recorder?
The WJ-NX400 supports multiple RAID configurations to protect against storage failures. RAID redundancy ensures continuous recording and data integrity, critical for surveillance systems where footage loss could compromise security compliance and incident investigation capabilities.
