InVid Tech VN2A-128: 128 Channel NVR
The InVid Tech VN2A-128 is a professional-grade 128 channel NVR designed for large-scale IP video deployments requiring high-bandwidth recording and simultaneous multi-channel monitoring. This 128 Ch NVR supports up to 512 Mbps of incoming bandwidth, making it ideal for enterprises, government facilities, and security integrators managing complex surveillance infrastructure. With 16 hard drive bays, 4K resolution support, and the ability to display 64 channels simultaneously (expandable to all 128 with optional hardware), the VN2A-128 delivers enterprise-class performance for mission-critical video recording and playback.
Key Features
- 128 channel network video recorder with 512 Mbps bandwidth support
- 16 hard drive bays for extended storage capacity
- 4K resolution recording and playback capability
- Simultaneous display of up to 64 channels on primary interface
- Four NIC cards for redundant network connectivity
- Optional VIS-HDMI4 4-port expansion card for full 128-channel display
- Cloud upgrade option for remote access and hybrid storage
- Vision Series professional surveillance platform
- Scalable architecture for large IP video deployments
Technical Specifications
| Specification |
Details |
| Manufacturer |
INNOVATIVE VIDEO TECHNOLOGY |
| Model |
VN2A-128 |
| Part Number |
VN2A-128/2TB |
| Channel Capacity |
128 channels |
| Bandwidth Support |
512 Mbps incoming |
| Display Channels |
64 simultaneous (expandable to 128 with VIS-HDMI4) |
| Hard Drive Bays |
16 bays |
| Network Interfaces |
4 NIC cards |
| Video Resolution |
4K support |
| Optional Features |
Cloud upgrade, VIS-HDMI4 4-port expansion |
| Series |
Vision Series |
Frequently Asked Questions
What is a 128 channel NVR used for?
A 128 channel NVR is used for large-scale surveillance deployments where organizations need to record and monitor multiple IP cameras simultaneously. The InVid Tech VN2A-128 is ideal for enterprise campuses, transportation hubs, government facilities, and security operations centers requiring centralized video management across hundreds of camera feeds.
How much bandwidth does the VN2A-128 support?
The InVid Tech VN2A-128 supports up to 512 Mbps of incoming bandwidth, allowing simultaneous recording from numerous high-resolution cameras without bottlenecking. This high-bandwidth capacity ensures smooth 4K recording and playback across all 128 channels.
Can I view all 128 channels at once on the VN2A-128?
The VN2A-128 displays up to 64 channels simultaneously on the primary interface. To view all 128 channels at once, you can install the optional VIS-HDMI4 4-port expansion card, which enables full 128-channel display across multiple monitors.
Does the VN2A-128 support 4K recording?
Yes, the 128 channel NVR supports 4K resolution recording and playback, allowing you to capture high-definition video from modern IP cameras. Combined with the 16 hard drive bays and 512 Mbps bandwidth, the VN2A-128 delivers professional-grade 4K surveillance for demanding applications.
