Altronix eBridge1PCRM - IP Over Coax Receiver
eBridge1PCRM is a single port EoC Receiver which transmits data and passes power over coax cable. eBridge1PCRM passes PoE/PoE+ up the coax to an eBridge1PCT or eBridge1PCTX transceiver. The transceiver in turn delivers that PoE compliant power to an edge device/camera. This plug and play unit facilitates system upgrades from analog to IP utilizing existing legacy Coax and eliminates the costs and labor associated with installing new network cabling. Data transmission and power over the Coax is possible up to 457m in comparison to 100m Ethernet distance (CAT5e). A maximum range from head end to the edge device/camera is 657m taking into consideration that up to 100m of structured cable may be deployed from the receiver to the network switch and the transceiver to the edge device/camera. Lifetime warranty. Made in the U.S.A.
- Supports PoE (IEEE 802.3af) or PoE+ (IEEE 802.3at).
- UL/cUL Listed. CE Approved.
- 25Mbps full duplex.
- Transmits IP video/data over coax up to 457m.
- Ethernet over coax/CAT5e Receiver.
Product Type: Transceiver/Media Converter
Environmentally Friendly: Yes
Environmental Certification: RoHS
Country Of Origin: United States
Brand Name: Altronix
Manufacturer: Altronix Corporation
Product Model: eBridge1PCRM
Product Name: eBridge1PCRM - IP Over Coax Receiver
Product Line: eBridge
Manufacturer Part Number: EBRIDGE1PCRM
Manufacturer Website Address: http://www.altronix.com
Packaged Quantity: 1
Limited Warranty: Lifetime
Weight (Approximate): 5.09 oz
