Altronix IP Access FACP Adapter Kit ENTRADA2DMK

Altronix IP Access FACP Adapter Kit
Altronix Entrada2DMT and Entrada2DMR adapters are specifically designed to interface with Network Door Controllers. They route power (PoE/PoE+) from a PoE switch or Midspan to the Network Door Controller and accommodate up to two (2) Fail-Secure strikes or Fail-Safe mag locks. The receiver features a supervised Fire Alarm Disconnect which releases locking devices while maintaining power to the Network Door Controller. The Fire Alarm Interface feature allows multiple units to be interconnected enabling any or all to be affected from a single FACP trigger input.

• Lifetime Warranty / Made in the U.S.A.


• CSFM Approved.


• CE Approved.


• UL Listed in the U.S. and Canada.


• Normally Open (N.O.) or Normally Closed (N.C.) trigger input.


• Supervised Fire Alarm Disconnect is selectable for


• Fire Alarm input trigger allows to disconnect lock power without dropping power to the IP/PoE Access Control Panel.


• Single PoE+ input powers up to two (2) locks and one (1) access controller.


• IEEE 802.3af (15W) and IEEE 802.3at (30W).

Product Type: Connector Adapter Kit
Country Of Origin: United States
Brand Name: Altronix
Manufacturer: Altronix Corporation
Product Name: IP Access FACP Adapter Kit
Manufacturer Part Number: ENTRADA2DMK
Manufacturer Website Address: http://www.altronix.com
Package Contents:

• Receiver
• Transmitter
