Kramer ASPEN-1616UX 12G SDI Matrix Switcher
The Kramer ASPEN-1616UX is a professional-grade 12G SDI matrix switcher engineered for broadcast, live production, and AV integration environments requiring high-performance signal routing. This 16x16 matrix switcher delivers seamless SDI signal management with integrated equalization and reclocking technology, enabling extended-reach signal extension across complex video distribution systems. Ideal for control rooms, broadcast facilities, and large-scale AV installations, the ASPEN-1616UX simplifies routing operations through intuitive web-based interfaces and RS-232 serial control, making it the preferred choice for demanding professional applications.
Key Features
- 16x16 matrix configuration for flexible SDI signal routing and switching
- 12G SDI support for 4K and ultra-high-definition video signal compatibility
- Input signal equalization for signal integrity across extended cable runs
- Output signal reclocking to maintain timing and synchronization
- Extended-reach signal extension capabilities for distributed installations
- Intuitive web-based control interface for remote operation and management
- RS-232 serial controller support for integration with existing control systems
- Professional-grade construction for 24/7 broadcast and production environments
Technical Specifications
| Specification |
Details |
| Manufacturer |
Kramer Electronics |
| Model |
ASPEN-1616UX |
| Part Number |
20-00018490 |
| Matrix Configuration |
16 Input x 16 Output |
| Signal Format |
12G SDI |
| Signal Equalization |
Yes - Input equalization for extended-reach |
| Signal Reclocking |
Yes - Output reclocking for timing recovery |
| Control Interface |
Web-based GUI, RS-232 serial |
| Application |
Broadcast, live production, AV integration |
Frequently Asked Questions
What is a 12G SDI matrix switcher used for?
A 12G SDI matrix switcher like the ASPEN-1616UX routes multiple video sources to multiple destinations in broadcast and production environments. The 16x16 configuration allows any of 16 input signals to be switched to any of 16 output destinations, enabling flexible signal management in control rooms, live events, and distributed AV systems.
How does signal equalization and reclocking improve video quality?
The ASPEN-1616UX equalizes incoming SDI signals to compensate for cable loss and signal degradation over extended distances. Output reclocking recovers timing information and regenerates clean digital signals, ensuring video integrity and synchronization across your entire distribution network.
Can the Kramer ASPEN-1616UX be controlled remotely?
Yes, the ASPEN-1616UX offers dual control options: intuitive web-based pages for browser-based remote management and RS-232 serial control for integration with professional control systems and automation platforms, providing flexibility for various installation requirements.
Is the ASPEN-1616UX compatible with 4K video signals?
Yes, the 12G SDI support ensures full compatibility with 4K and ultra-high-definition video formats, making the ASPEN-1616UX suitable for next-generation broadcast and production workflows requiring high-resolution signal routing.
