Kramer VS-44H2 4x4 4K HDR Matrix Switcher
The Kramer VS-44H2 is a professional-grade 4x4 matrix switcher engineered for demanding AV installations requiring 4K HDR signal routing with HDCP 2.2 security compliance. This HDMI matrix switcher enables seamless distribution of any one of four 4K inputs to any or all four outputs simultaneously, making it ideal for control rooms, broadcast facilities, corporate boardrooms, and luxury residential installations where reliable 4K signal management is critical. Whether you're managing multiple 4K video sources or distributing premium content across multiple displays, the VS-44H2 delivers professional-grade switching performance with zero signal degradation at 4K 60Hz.
Key Features
- 4x4 HDMI matrix switching — route any input to any output independently
- 4K at 60Hz support with HDR pass-through for premium video quality
- HDCP 2.2 compliant for secure content distribution and copy protection
- Flexible output configuration — send same or different sources to each display
- Professional AV integration ready with standard control interfaces
- Compact form factor designed for rack or desktop deployment
Technical Specifications
| Specification |
Details |
| Manufacturer |
Kramer Electronics |
| Model Number |
VS-44H2 |
| Part Number |
20-80445130 |
| Matrix Configuration |
4 HDMI Inputs × 4 HDMI Outputs |
| Video Resolution |
4K (3840×2160) at 60Hz |
| HDR Support |
Yes — HDR10, Dolby Vision compatible |
| HDCP Version |
HDCP 2.2 |
| Color Depth |
Up to 12-bit |
| Audio Support |
HDMI embedded audio pass-through |
| Switching Speed |
Instant switching with no signal loss |
Frequently Asked Questions
What is a 4x4 matrix switcher and how does it work?
A 4x4 matrix switcher like the VS-44H2 accepts four independent HDMI inputs and routes them to four HDMI outputs. Each output can independently display any input source, allowing you to send different 4K signals to different displays simultaneously or duplicate one source across multiple screens — all without interrupting video playback.
Does the Kramer VS-44H2 support 4K HDR content?
Yes. The VS-44H2 is fully optimized for 4K HDR signals at 60Hz refresh rate. It passes through HDR metadata and supports HDR10 and Dolby Vision formats, making it ideal for professional installations requiring premium video quality and color accuracy.
Why is HDCP 2.2 important for my AV setup?
HDCP 2.2 is the current copy protection standard required for streaming 4K premium content from services like Netflix, Disney+, and professional broadcast sources. The VS-44H2's HDCP 2.2 compliance ensures you can route protected content without authentication failures or signal drops.
Can I use the VS-44H2 in a professional control room or broadcast environment?
Absolutely. The VS-44H2 is designed for professional AV integration in control rooms, broadcast facilities, and corporate environments. Its instant switching capability, 4K 60Hz performance, and HDCP 2.2 support make it a reliable choice for mission-critical signal distribution applications.
