Kramer VS-84H2 8x4 4K HDR Matrix Switcher with Digital Audio Routing
The VS-84H2 8x4 matrix switcher is engineered for professional AV integrators and system designers who demand reliable 4K signal distribution with advanced HDCP 2.2 protection. This 4K HDR HDMI matrix switcher delivers pristine video and audio routing across eight inputs to four outputs, making it ideal for corporate boardrooms, broadcast facilities, education centers, and large-scale AV installations. With integrated digital audio routing and automatic signal recloking, the VS-84H2 ensures flawless content delivery in mission-critical environments where downtime is not an option.
Key Features
- 8x4 HDMI matrix switching with 4K@60Hz (4:4:4) support
- Full HDCP 2.2 compliance for protected content distribution
- HDR (High Dynamic Range) passthrough for enhanced color and contrast
-
Integrated digital audio routing with independent audio control
- Automatic signal recloking and equalization for extended cable runs
- EDID management and 3D video support
- Professional-grade reliability for 24/7 operation
- Compact form factor suitable for rack or desktop mounting
Technical Specifications
| Specification |
Details |
| Manufacturer |
KRAMER ELECTRONICS |
| Model |
VS-84H2 |
| Part Number |
20-00011730 |
| Matrix Configuration |
8 HDMI Inputs × 4 HDMI Outputs |
| Video Resolution |
4K@60Hz (4:4:4), Full HD, HD |
| Color Depth |
12-bit (4:4:4 chroma sampling) |
| HDCP Support |
HDCP 2.2 |
| HDR Support |
Yes (HDR passthrough) |
| 3D Support |
Yes |
| Audio Routing |
Digital audio routing with independent control |
| Signal Processing |
Automatic recloking and equalization |
| EDID Management |
Yes |
| Power Consumption |
Typical 60W |
| Operating Temperature |
0°C to 40°C |
Frequently Asked Questions
What is an 8x4 matrix switcher and how does it work?
An 8x4 matrix switcher allows you to route any of 8 HDMI input sources to any of 4 output displays independently. The VS-84H2 lets you switch between multiple video sources (cameras, computers, media players) and send them to different displays simultaneously, perfect for multi-display environments and complex AV systems.
Does the VS-84H2 support 4K HDR content?
Yes, the VS-84H2 fully supports 4K HDR HDMI signals at 4K@60Hz with 4:4:4 chroma sampling and HDR passthrough. It maintains HDCP 2.2 protection for premium content, making it ideal for streaming services, broadcast, and professional video production workflows.
Can I route audio independently from video?
Absolutely. The digital audio routing feature allows you to separate audio and video paths, enabling flexible audio distribution to different zones or systems while maintaining video switching independence. This is essential for complex installations with multiple audio destinations.
What makes the VS-84H2 suitable for professional installations?
The VS-84H2 combines automatic signal recloking, EDID management, extended cable run support, and 24/7 reliability in a compact form factor. These professional-grade features ensure stable operation in demanding AV environments without signal degradation or compatibility issues.
