Legrand 24-Fiber OS2 M4 Cassette with LC Quad Adapters
The Legrand OS2 M4 cassette delivers enterprise-grade 24-fiber connectivity in a compact, high-density form factor. Designed for mission-critical data center and telecommunications deployments, this LC quad adapter cassette provides reliable single-mode fiber connectivity with two MPO male interfaces in a Tier 1 configuration. Perfect for organizations requiring maximum fiber density without sacrificing performance, the M4 cassette integrates seamlessly into HDFP, LM4, and M4 housings for flexible infrastructure scaling.
Key Features
- 24-fiber OS2 single-mode connectivity with LC quad adapters
- Two MPO male interfaces for high-density patch panel integration
- Q-Series high-density footprint optimized for compact installations
- Compatible with HDFP, LM4, and M4 housing systems
- Tier 1 configuration ensures standards-compliant performance
- Supports enterprise data center and telecommunications applications
- Reduced footprint enables maximum fiber density per rack unit
Technical Specifications
| Specification |
Details |
| Manufacturer |
Legrand DAT |
| Part Number |
M4LCQ24-09A1A2 |
| Fiber Type |
OS2 Single-Mode |
| Fiber Count |
24 fibers |
| Adapter Type |
LC Quad |
| Interface Connectors |
2x MPO Male |
| Configuration |
Tier 1 |
| Form Factor |
Q-Series High-Density |
| Compatible Housings |
HDFP, LM4, M4 |
Frequently Asked Questions
What is an OS2 M4 cassette used for?
An OS2 M4 cassette is used in high-density fiber optic installations to provide 24-fiber connectivity in data centers, telecommunications facilities, and enterprise networks. The LC quad adapter configuration allows multiple fiber connections through a compact MPO interface.
How many fibers does this LC quad cassette support?
This Legrand cassette supports 24 fibers through four LC quad adapters, each containing six fiber connections. The dual MPO male interfaces enable efficient integration into patch panel systems.
Is the Legrand M4 cassette compatible with existing infrastructure?
Yes, the M4 cassette is designed for compatibility with HDFP, LM4, and M4 housing systems, making it ideal for upgrades and expansions in existing Legrand fiber optic installations.
What makes this high-density fiber solution Tier 1 compliant?
The Tier 1 configuration ensures this OS2 single-mode cassette meets industry standards for performance, reliability, and interoperability in mission-critical telecommunications and data center environments.
