- Logic family of four sizes and lumen packages (S, M, L, XL)
- Compact and slim design
- Superior color consistency based on factory calibration
- Color boost for bright saturated and mixed colors
- Dedicated color temperature control channel
- Narrow beam-angle using high-power RGBW LEDs
- Optional baffle snoot
- Externally mounted micro lens diffusers
- RDM and DMX control
- Local diagnostics and focusing via magnetic sensor
- Power and DMX IN/OUT pre-mounted cables
- Optional Hybrid IN/Out cable solution
- Fully weatherized housing (IP66, IK08 and C-5 High corrosion rating)
- Shipped in FSC certified carboard packaging
- 5-year warranty
Specifications
Physical
- Length: 141 mm (5.55 inch.)
- Width: 155 mm (6.10 inch.)
- Height: 236 mm (9.29 inch.)
- Weight: 4.4 kg (9.7 lbs)
Dynamic Effects
- Intensity: 0 - 100 %
- Color mixing: RGB + CTC (Color Temperature Control)
- Color temperature control: 1000 K - 12500K in 50K steps
Control and Programming
- Control systems: DMX, RDM
- User interface: Magnetic sensor for local diagnostics and focusing
- Stand-alone control: Up to 20 scenes with individual fade/hold times
- Control resolution: 8-bit DMX control of each color
- Dimmer resolution: 16-bit DMX control of intensity
- DMX channels: 6/3/7/4 (Standard/Basic/Extended/Raw)
- DMX compliance: USITT DMX512/1990
- RDM compliance: ANSI/ESTA E1.20
- DMX/RDM Transceiver: Galvanic-isolated RS-485
- Firmware update: Serial upload via DMX link
Optics
- Light source: 4 x high-power RGBW LEDs
- LED Manufacturer: Osram
- Minimum LED lifetime: 100 000 hours (to >70% luminous output)*
- Binning: Tight color and flux binning
- Calibration: Full Gamut Color Calibration (1 step MacAdam ellipse)
Beam Angle Options
- Native beam angle: 8°
- Narrow micro lens: 11°
- Medium micro lens: 15°
- Wide micro lens: 30°
- Very Wide micro lens: 50°
- Asymmetric micro lens: 8°x 50°
Photometric Data
- CRI: 70
- CCT: 1000K - 12500K (default 4000K)
Luminous Output
- Full: 1800 lm
- Red: 620 lm
- Green: 1320 lm
- Blue: 470 lm
Construction
- Housing: Cast Aluminum
- Surface treatment: Anodized and electrostatic powder-coated
- Color: Traffic grey RAL 7042 - other colors available on request
- Effective Projected Area (EPA): 0.026 m² / 0.038 m²
- Protection rating: IP66
- Impact resistance: IK08
- Corrosion resistance: C5 High (ISO 12944-6)
- Vibration resistance: 1.0g, Sinusoidal (IEC 60068-2-6), 0,7g RMS Random (IEC 60068-2-64), 3.0g ANSI C136-31)
Installation
- Orientation: Any
- Mounting: Adjustable bracket
- Minimum distance to illuminated surfaces: 0.1 m (0.3 ft.)
Electrical
- AC power: 100 -240 / 277 V nominal, 50/60 Hz
- Power supply unit: Auto-ranging electronic switch-mode
- Typical half-cycle RMS inrush current: 12A
- Max earth leakage: 0.5 mA
- Power factor: 0.99 @ 110 V / 120 V, 0.94 @ 208 V / 230V, 0.90 @ 277 V
- Surge protection: 4KV
