Description
OREI 1 in 8 out HDMI Splitter 4K@30Hz with Advanced EDID Management, HDR & Dolby Vision
Key Features:
HDMI 1.4 & HDCP 1.4 compliant.
Video resolutions up to 4K@30Hz, including 1080P 3D@60Hz
10.2Gbps video bandwidth
Digital audio formats such as DTS-HD/Dolby-true-HD/LPCM 7.1/ DTS/Dolby-AC3/DSD are supported.
HDR, HDR10+ & Dolby-Vision pass-through
Does NOT extend laptop or PC display to have different programs on all screens
Compact design and plug-and-play setup
The OREI HD-108 HDMI Splitter 1 in 8 out allows you to distribute an HDMI signal to eight displays simultaneously. Supporting video resolutions up to 4K@30Hz, with HDR, Dolby Vision pass-through, and 3D support. It is compliant with HDMI 1.4 and HDCP 1.4 standards. You can connect various media devices such as cable boxes, laptops, Fire TV sticks, and Apple TVs, and duplicate their content across eight different displays at the same time. The splitter features advanced EDID management which can be accessed by a set of 2 switches. With no additional drivers required, it offers a straightforward plug-and-play installation process. Ideal for both commercial and personal home theater setups, this splitter is the perfect solution for distributing media content to multiple screens.
[shortdes]
1 in 8 out HDMI Splitter
Video resolutions up to 4K@30Hz
Advanced EDID management, HDR10+ & Dolby vision support
[/shortdes]
[tab]
CONNECTIVITY
INPUT:
1 × HDMI [Type A, 19-pin female]
OUTPUT:
8 × HDMI [Type A, 19-pin female]
PACKAGE CONTENTS
1x HD-108
1x Power adapter
User Manual
SUPPORTED HDMI CABLES
HDMI 2.0/2.1
We recommend using high-quality HDMI 2.0/2.1 cables under 30 feet for optimum performance
Our splitters will not work with capture cards due to the HDCP encryption on the output
Our HDMI splitter will duplicate or "mirror" a single HDMI source on two HDMI displays. Both displays will show the same video and audio simultaneously
Our splitter does not support extend mode. It only supports mirror/duplicate screen function, each screen will show the same picture
Yes, the power adapter does support 220V
You can use standard HDMI cables up to 15 feet and high quality cables up to 30 feet.
However, you can use fiber optic active HDMI cables up to 200 feet. If its not a high quality cable then you may lose the signal in some instances.
No, the HDMI splitters do not support CEC because most customers do not want all the TV's to turn ON as soon as the source is turned ON.
