ArmorLogix

Ovpoe24X-400-2Gc- 24 Port Poe + 2Gb Switch 10/100/1000 Mbps Ovpoe24X-400-2Gc

Ovpoe24X-400-2Gc- 24 Port Poe + 2Gb Switch 10/100/1000 Mbps Ovpoe24X-400-2Gc

SKU:OVPOE24X-400-2GC

Shipping calculated at checkout.
View full details
Description
Specifications
Reviews, Que. & Ans.

Description :

OVPOE24X-400-2GC – 24 PORT POE + 2GB SWITCH 10/100/1000 MBPS OVPOE24X-400-2GC



  • 24 x 10/100/1000Base-TX
  • 2 x GB Uplink
  • 400W Power over Ethernet

OVERVIEW

The OVPOE24X-400-2GC PoE switch provides power for regular IP cameras, and IP PTZ cameras, as well as other data and infrastructure. 10/100/1000Gbps speeds ensure high definition video quality.

FEATURES:
  • Conforms to IEEE802.3, IEEE 802.3u, IEEE 802.3ab,IEEE802.3af, IEEE802.3at
  • 24 x 10/100/1000Base-TX ports + 2 Gigabit Combo
  • Provides 24 x PoE Injector and 400W built-in power supply and 30W per port
  • High back-plane bandwidth 52Gbps
  • IEEE802.3x Flow control
  • EMI standards complies with FCC, CE class B

SPECIFICATIONS

Power Supply   Built-In Power Supply
Voltage Range   AC110V~240V
Switch Consumption   <15W
Speed   1~24 Port: 10/100/1000Mbps
Speed   25~26: Gigabit Combo
Transmission Distance   328ft for RJ-45
Transmission Distance   2Km 20Km for SFP Port The Optical module is optional
Ethernet Standard   IEEE 802.3/802.3u/802.3ab/802.3af/at
Switching Capacity   52G
Transfer Rate   14,880pps for 10Mbps
Transfer Rate   148,800pps for 100Mbps
Transfer Rate   1,488,000pps for 1000Mbps
MAC Address   8K MAC address table
On / Green   The port is connecting
Blinks   The port is receiving or transmitting data
Off   The port is not linked successfully with the device
On / Orange   PD is connected
Off   No PD is connected or power forwarding fails
Total Output Capacity   400W
Output Capacity per Port   Up to 30W per port
PoE Pin Assignment   V+(RJ45 Pin 1,2), V-(RJ45 Pin 3,6)
Working Temperature   0~40℃
Storage Temperature   -40~70℃
Humidity (Non-Condensing)   0~90%
Dimension   17.3″ x 7.9″ x 1.7″
Color   Black

RESOURCES

Product Spec Sheet – Download
