Panduit FY9WP77B005F111 48-Fiber ST Trunk Cable
The Panduit FY9WP77B005F111 48-fiber ST trunk cable is engineered for data center managers, telecommunications professionals, and network infrastructure teams who demand rapid deployment without compromising performance. This single-mode trunk cable assembly eliminates time-consuming field terminations, delivering pre-terminated ST connectors ready for immediate installation. At 111 feet, it spans critical backbone connections while maintaining signal integrity across high-density fiber networks. The plenum-rated OFNP jacket ensures compliance with building codes and safety standards for air-handling spaces, making it the ideal choice for enterprise-grade telecommunications room buildouts.
Key Features
- 48-fiber configuration for maximum density and scalability
- Pre-terminated ST connectors reduce installation time and labor costs
- Single-mode fiber supports long-distance, high-bandwidth transmission
- 111-foot length ideal for backbone and trunk applications
- Plenum-rated OFNP jacket meets fire and smoke codes
- Factory-tested for reliability and performance assurance
- Reduces on-site termination complexity in data centers
Technical Specifications
| Specification |
Details |
| Manufacturer |
PANDUIT CORP |
| Part Number |
FY9WP77B005F111 |
| Fiber Count |
48 fibers |
| Fiber Type |
Single-mode |
| Connector Type |
ST (pre-terminated) |
| Cable Length |
111 feet (33.8 meters) |
| Jacket Rating |
OFNP (plenum-rated) |
| Application |
Data center trunk, telecommunications backbone |
| Termination |
Factory pre-terminated |
Frequently Asked Questions
What is a 48-fiber ST trunk cable used for?
A 48-fiber ST trunk cable connects high-capacity backbone infrastructure in data centers and telecommunications rooms. The 48-fiber configuration supports multiple channels simultaneously, making it ideal for aggregating traffic between network switches, routers, and distribution frames. Pre-terminated connectors enable rapid deployment without field splicing.
Why choose plenum-rated OFNP cable for data centers?
Plenum-rated OFNP (Optical Fiber Non-Conductive Plenum) cable is required by building codes when installed in air-handling spaces above drop ceilings or in HVAC plenums. It produces minimal smoke and toxic fumes if exposed to fire, protecting personnel and equipment. The Panduit FY9WP77B005F111 meets these safety standards while delivering reliable single-mode performance.
How does pre-termination reduce installation time?
Factory pre-terminated ST connectors eliminate the need for on-site fiber splicing, polishing, and testing. Technicians simply connect the cable ends to network equipment, reducing labor hours and potential field errors. This accelerates data center buildouts and minimizes service disruption during infrastructure upgrades.
Is single-mode fiber better than multimode for trunk cables?
Single-mode fiber supports longer distances (up to 10+ km) and higher bandwidth than multimode, making it the standard for backbone and trunk applications. The Panduit 48-fiber single-mode trunk cable ensures future-proof performance for enterprise telecommunications networks and large-scale data center interconnects.
