Panduit OS2 24F Trunk OFNP MPO Breakout Cable 165ft
The Panduit F9UYP5353AAF165 OS2 24F trunk cable delivers high-density fiber connectivity for demanding data center and enterprise network environments. This MPO F/MPO F breakout cable combines singlemode OS2 performance with OFNP plenum rating, making it ideal for indoor deployments requiring flexible cable management and reliable singlemode fiber connectivity. With an 18-inch breakout design and HD Flex construction, this 165-foot trunk cable simplifies high-density fiber installations while maintaining standard insertion loss performance.
Key Features
- OS2 singlemode fiber for long-distance, high-bandwidth transmission
- 24-fiber trunk configuration with MPO female connectors on both ends
- OFNP plenum-rated for safe installation in air handling spaces
- 18-inch breakout with HD Flex design for superior cable management
- Standard insertion loss performance for reliable signal integrity
- 165-foot length ideal for backbone and inter-cabinet connectivity
- Pull eye for easy cable routing and deployment
- Type A standard configuration for industry compatibility
Technical Specifications
| Specification |
Details |
| Manufacturer |
PANDUIT CORP |
| Part Number |
F9UYP5353AAF165 |
| Fiber Type |
OS2 Singlemode |
| Fiber Count |
24 fibers |
| Connector Type |
MPO Female / MPO Female |
| Cable Length |
165 feet |
| Breakout Length |
18 inches |
| Cable Design |
HD Flex Type A |
| Plenum Rating |
OFNP (Optical Fiber Non-Conductive Plenum) |
| Insertion Loss |
Standard IL Performance |
| Application |
Indoor high-density fiber backbone and inter-cabinet connectivity |
Frequently Asked Questions
What is an OS2 singlemode fiber trunk cable used for?
OS2 singlemode fiber trunk cables like the Panduit 24F configuration are designed for high-bandwidth, long-distance backbone connectivity in data centers and enterprise networks. The 24-fiber count enables efficient consolidation of multiple fiber pairs into a single trunk, reducing cable clutter and improving cable management in high-density environments.
Why choose OFNP plenum-rated fiber optic cable?
OFNP plenum rating ensures the cable meets fire safety standards for installation in air handling spaces and plenum areas. This rating is critical for compliance in commercial buildings and data centers where cables run through HVAC return air plenums, providing both safety and regulatory compliance.
How does HD Flex breakout design improve cable management?
The HD Flex breakout design with an 18-inch fan-out provides superior flexibility and bend radius performance compared to standard breakouts. This allows easier routing around obstacles, tighter cable management in high-density racks, and reduced stress on individual fibers during installation and maintenance.
What is the difference between MPO Type A and Type B connectors?
Type A and Type B refer to the polarity arrangement of fibers within the MPO connector. The Panduit OS2 24F trunk uses Type A standard configuration, which is the most common for industry compatibility. Ensure your equipment supports Type A connectors to guarantee proper mating and signal integrity.
