Parsec Husky Series PRO9H 9-in-1 Antenna
The Parsec Husky PRO9H4L4WG01B-NF 9-in-1 antenna is engineered for enterprises, public safety agencies, and IoT deployments requiring high-performance connectivity across multiple standards. This rugged, multi-band antenna combines 4x4 MIMO LTE, 4x4 MIMO WiFi, and GNSS capabilities in a single integrated housing, delivering omnidirectional coverage from 600 MHz to 6 GHz. Whether you're deploying 5G infrastructure, mobile command centers, or distributed IoT networks, the Husky Series antenna provides the reliability and performance your mission-critical applications demand.
Key Features
- 9-in-1 integrated antenna combining LTE, WiFi, GNSS, and 5G in one housing
- 4x4 MIMO LTE support for enhanced data throughput and network reliability
- 4x4 MIMO WiFi capability for high-speed wireless connectivity
- Omnidirectional coverage pattern for 360-degree signal reception
- Frequency range: 600 MHz – 6 GHz for CAT18 and 5G applications
- Rugged bolt-mount design optimized for mobile and stationary deployments
- Enterprise-grade construction for public safety and IoT environments
- Compact form factor reduces installation complexity and space requirements
Technical Specifications
| Specification |
Details |
| Manufacturer |
PARSEC TECHNOLOGIES |
| Part Number |
PRO9H4L4WG01B-NF |
| Product Series |
Husky Series |
| Antenna Type |
9-in-1 Multi-Band Integrated Antenna |
| MIMO Configuration |
4x4 MIMO LTE, 4x4 MIMO WiFi |
| GNSS Support |
Yes |
| Frequency Range |
600 MHz – 6 GHz (CAT18, 5G) |
| Coverage Pattern |
Omnidirectional |
| Mount Type |
Bolt-Mount |
| Primary Applications |
Enterprise, Public Safety, IoT, Mobile Deployments |
Frequently Asked Questions
What is a 9-in-1 antenna and why do I need one?
A 9-in-1 antenna integrates multiple antenna functions into a single unit, eliminating the need for separate LTE, WiFi, and GNSS antennas. The Husky PRO9H consolidates connectivity standards, reducing installation complexity, saving space, and lowering total cost of ownership for enterprise and IoT deployments.
Does the Parsec Husky antenna support 5G connectivity?
Yes, the Husky Series PRO9H is designed for 5G and CAT18 applications, operating across the 600 MHz – 6 GHz frequency range. Its 4x4 MIMO LTE and WiFi capabilities ensure robust multi-band performance for next-generation mobile networks.
What are the advantages of 4x4 MIMO in this antenna?
4x4 MIMO technology enables simultaneous transmission and reception on four spatial streams, significantly increasing data throughput, reducing latency, and improving network reliability. This is critical for public safety communications and enterprise IoT applications requiring consistent, high-speed connectivity.
Is the Husky PRO9H suitable for outdoor mobile deployments?
Absolutely. The rugged bolt-mount design and omnidirectional coverage pattern make the Husky antenna ideal for mobile command centers, emergency response vehicles, and distributed IoT networks. Its enterprise-grade construction ensures reliable performance in demanding field conditions.
