Raritan Px3-5611R-E2 Power Distribution Unit (Pdu) 18 Ac Outlet(S) 2U Black

Raritan Px3-5611R-E2 Power Distribution Unit (Pdu) 18 Ac Outlet(S) 2U Black

SKU:PX3-5611R-E2

Regular price $2,574.11
Regular price Sale price $2,574.11
Sale Sold out
Shipping calculated at checkout.
          View full details
          Description
          Specifications
          Reviews, Que. & Ans.

          Description :

          Wi-Fi, Ethernet, IP20, 208V, 50A, 50 - 60 Hz, 208V, IEC320 C13, IEC60320 C19, 440 x 293 x 88 mm

          Raritan PX3-5611R-E2. PDU types: Monitored, Switched, Rack capacity: 2U, Type: Three-phase. AC outlets quantity: 18 AC outlet(s), AC outlet types: C13 coupler, C19 coupler, Power plug: IEC 320. LED indicators: Status, Cable length: 3 m. Monitoring: Humidity, Temperature, Management protocols: HTTP(s); SSH; Telnet; RS-232 (Serial); Power IQ; SNMP version v2/v3; SMTP; JSON-RPC; Modbus over.... Nominal input voltage: 208 V, Maximum current: 50 A, AC input frequency: 50 - 60 Hz

          Monitored and switched rack power distribution unit (2U [horizontal], 14.4kVA, 18 outlets). INPUT: 208v (3-phase DELTA), 50a - CS8365C plug (3P4W); OUTPUT: 6@ C13, 12@ C19 outlets; on 6@ 2-pole, 20a Overcurrent Protectors; FEATURES: Billing-Grade (+/- 1%) Energy Metering [kW, kVA, V, A, Power Factor] - per inlet, per breaker/fuse, per outlet; Remote network monitoring via HTML, JSON-RPC, SSH, Telnet, MODBUS/TCP, and SNMPv3. Onboard embedded processor with minimum 536MHz clock speed, 16MB SPI Flash, and 64MB DDR2 RAM. Cascading upto 16 PDU's using single Ethernet or USB connection. Environmental monitoring [temp/humidity] capable – up to 32 sensors. Individual outlet numbers labeled on chassis. Automated deployment via TFTP, DHCP, SSH(CLI), or USB Flash Drives. WiFi Capable. USB Webcam Capable. iPad/iPhone/Android App. Dual 10/100/1000 Ethernet port. Tri-color status LED per receptacle. Breaker metering and alarming (0V detection). Max Dimensions 440mm x 293mm x 88mm (17.3in x 11.5in x 3.5in). Max Weight TBD. Maximum ambient temperature 60C at full load.

          Specifications :

          General Information

          Manufacturer Legrand Group
          Manufacturer Part Number PX3-5611R-E2
          Manufacturer Website Address http://www.legrand.us
          Brand Name Raritan
          Product Series PX3
          Product Model PX3-5611R-E2
          Product Name PX3-5611R-E2 (6) IEC320 C13, (12) IEC320 C19 PDU
          Product Type PDU
          Network (RJ-45)Yes
          Height3.5"
          Width17.3"
          Depth11.5"

          Warranty

          Limited Warranty2 Year
