Samsung LHX Series 10mm Outdoor LED Display
The Samsung LHX10VTD4C0 is a professional-grade outdoor LED display engineered for demanding signage applications where brightness and durability matter. With exceptional 7000 cd/m² brightness and a robust 7000:1 contrast ratio, this 10mm pixel pitch video wall delivers stunning visual impact in direct sunlight and high-ambient-light environments. Ideal for retail, transportation hubs, stadiums, and outdoor advertising, the LHX Series combines Samsung's display expertise with rugged construction for mission-critical outdoor installations.
Key Features
-
7000 cd/m² brightness — Exceptional visibility in direct sunlight and bright outdoor conditions
-
10mm pixel pitch — Optimal viewing distance for outdoor signage and video walls
-
7000:1 contrast ratio — Deep blacks and vibrant colors for striking visual content
-
281 trillion colors — 24-bit color depth for photorealistic imagery
- Wide viewing angles — Horizontal and vertical coverage for diverse audience positions
-
100,000-hour service life — Extended operational lifespan reduces maintenance costs
- Temperature resilient — Operates reliably from -40°C to 55°C in extreme climates
- Efficient power management — 870W typical consumption with 100–240V, 50/60Hz compatibility
Technical Specifications
| Specification |
Value |
| Manufacturer |
Samsung |
| Model |
LHX10VTD4C0 |
| Display Type |
Outdoor LED Video Wall |
| Pixel Pitch |
10mm (0.41 x 0.41 inches) |
| Brightness |
7000 cd/m² |
| Contrast Ratio |
7000:1 (typical) |
| Color Depth |
24-bit (281 trillion colors) |
| Service Life |
Up to 100,000 hours |
| Operating Temperature |
-40°C to 55°C |
| Power Consumption (Typical) |
870W |
| Power Consumption (Maximum) |
3400W |
| Input Voltage |
100–240V, 50/60Hz |
Frequently Asked Questions
What is the best viewing distance for a 10mm pixel pitch outdoor LED display?
A 10mm pixel pitch is optimized for viewing distances of 10 meters and beyond, making it ideal for outdoor signage, billboards, and large venue displays where audiences view from a distance. This pitch balances image clarity with cost-effectiveness for outdoor applications.
How does 7000 cd/m² brightness compare to other outdoor LED displays?
At 7000 cd/m², the Samsung LHX Series delivers exceptional brightness suitable for direct sunlight environments. This high luminance ensures visibility even in bright daylight, making it superior for outdoor advertising, transportation hubs, and sports venues where ambient light is intense.
Can the Samsung LHX10VTD4C0 operate in extreme temperatures?
Yes, the LHX Series operates reliably across an extended temperature range from -40°C to 55°C, making it suitable for diverse climates—from cold northern regions to hot desert environments. This temperature resilience ensures consistent performance year-round.
What maintenance is required for this outdoor LED video wall?
With a 100,000-hour service life, the Samsung LHX10VTD4C0 requires minimal maintenance. Regular cleaning to remove dust and debris, along with periodic system checks, will maximize longevity. The robust design is engineered to withstand harsh outdoor conditions with minimal intervention.
