This industrial ethernet switch is perfect for manufacturing facilities, industrial automation systems, and harsh environment installations who need reliable PoE power over ethernet connectivity. Our StarTech IES1G52UPDIN delivers:
-
DIN rail mountable design that simplifies installation in control panels
-
Rugged construction for demanding industrial environments
-
Power over ethernet adapter functionality eliminating separate power cables
-
Fiber ethernet switches compatibility for extended network reach
Key Features
-
6-port gigabit connectivity with 4 PoE+ RJ45 ports plus 2 SFP slots
-
Industrial-grade construction rated for extended temperature ranges
- Optimized for server rack network switch integration
- Consistent power over ethernet delivery up to 30W per port
-
DIN rail mounting system for secure panel installation
Technical Specifications
| Manufacturer |
StarTech.com |
| Model Number |
IES1G52UPDIN |
| Type |
Industrial Ethernet Switch |
| Port Configuration |
4 x PoE+ RJ45 Gigabit + 2 x SFP Fiber Slots |
| PoE Power Budget |
120W Total (30W per PoE ethernet switch port) |
| Operating Temperature |
-40°C to 75°C (-40°F to 167°F) |
| Mounting |
DIN Rail Compatible with industrial standards |
| Compatible Systems |
Industrial automation, IP cameras, wireless access points, VoIP phones |
Frequently Asked Questions
Q: What makes this different from standard ethernet switches?
A: This industrial ethernet switch features rugged construction, extended temperature operation, and DIN rail mounting specifically designed for harsh industrial environments where standard switches would fail.
Q: Can this switch work with fiber optic connections?
A: Yes, it includes 2 SFP slots for fiber ethernet switches connectivity. Perfect for extending networks over long distances in industrial facilities.
Q: How much power can each PoE port deliver?
A: Each power over ethernet adapter port delivers up to 30W — perfect for powering IP cameras, wireless access points, and industrial IoT devices.
Q: Is this suitable for server rack installation?
A: While designed for DIN rail mounting, it can integrate with server rack network switch configurations using appropriate mounting adapters for hybrid industrial-IT installations.
Industrial ethernet switch 6-port PoE DIN rail mountable for harsh environments. Rugged gigabit networking with fiber connectivity and industrial automation compatibility.
