1 Watt Low Power WRD650 Waveguide Load 6.5 GHz to 18 GHz, Brass
Who It's For & Why It's Great
The WRD650 waveguide load is engineered for RF and microwave testing applications requiring precision termination across the 6.5 GHz to 18 GHz frequency range. This 1 watt low power waveguide load delivers reliable impedance matching and signal absorption for laboratory measurements, system validation, and component characterization. Ideal for engineers and technicians working with broadband RF systems, this brass waveguide termination provides stable performance in demanding test environments where accurate power dissipation and minimal reflections are critical.
Key Features
- Frequency range: 6.5 GHz to 18 GHz broadband coverage
- 1 watt low power rating for safe bench-top operation
- WRD650 waveguide interface for standard compatibility
- Brass construction for durability and thermal stability
- Precision impedance matching minimizes VSWR
- Compact design for integration into test setups
- Reliable RF termination for measurement accuracy
Technical Specifications
| Specification |
Value |
| Manufacturer |
Strategic Sourcing |
| Part Number |
PEWRD650TR1000 |
| Product Type |
Waveguide Load |
| Waveguide Size |
WRD650 |
| Frequency Range |
6.5 GHz to 18 GHz |
| Power Rating |
1 Watt |
| Material |
Brass |
| Application |
RF/Microwave Testing and Termination |
Frequently Asked Questions
What is a waveguide load used for?
A waveguide load serves as a precision RF termination that absorbs microwave energy and provides impedance matching. It's essential for test measurements, preventing reflections, and protecting sensitive equipment during RF system characterization and troubleshooting.
Why choose a 1 watt low power waveguide load?
The 1 watt rating makes this load ideal for laboratory and bench-top applications where lower power levels are typical. It provides safe, reliable termination without requiring extensive cooling infrastructure while maintaining measurement accuracy.
What frequency range does the WRD650 cover?
This 6.5 GHz to 18 GHz waveguide load spans the upper microwave and lower millimeter-wave bands, making it suitable for broadband RF testing, satellite communications equipment validation, and modern wireless system characterization.
Is brass the best material for waveguide loads?
Brass offers excellent thermal conductivity, corrosion resistance, and electrical properties for RF applications. The brass waveguide construction ensures stable performance across temperature variations and extended operational life in demanding test environments.
