Taoglas MA9917 GuardianX 17-in-1 Wall Mount Combination Antenna
The Taoglas MA9917 GuardianX is a professional-grade 17-in-1 combination antenna engineered for demanding IoT, automotive, and telematics applications. This wall mount antenna integrates active GPS/GLONASS/Galileo positioning, eight 5G/4G cellular MIMO elements, and eight Wi-Fi 6 MIMO channels into a single compact, IP67-rated enclosure. Perfect for fleet management, connected vehicles, and industrial IoT deployments where reliable multi-band connectivity and space efficiency are critical, the GuardianX delivers enterprise-grade performance in a low-profile design.
Key Features
- 17-in-1 integrated antenna system with GNSS, 5G/4G MIMO, and Wi-Fi 6 MIMO
- Active GPS/GLONASS/Galileo positioning for precise location tracking
- Eight 5G/4G cellular MIMO elements for enhanced signal strength and reliability
- Eight Wi-Fi 6 MIMO elements for high-speed wireless connectivity
- IP67-rated waterproof enclosure for outdoor and harsh environment deployment
- Low-profile wall mount design saves space in vehicle and IoT installations
- Operates across 600MHz to 6000MHz frequency range including Band 71 support
- High efficiency and isolation across all integrated antenna elements
- Heavy-duty construction for automotive and industrial applications
Technical Specifications
| Specification |
Details |
| Manufacturer |
TAOGLAS USA INC. |
| Part Number |
MA9917.A.001.WM |
| Product Type |
17-in-1 Wall Mount Combination Antenna |
| GNSS Support |
GPS, GLONASS, Galileo (Active) |
| Cellular MIMO Elements |
8x 5G/4G LTE |
| Wi-Fi MIMO Elements |
8x Wi-Fi 6 (802.11ax) |
| Frequency Range |
600MHz to 6000MHz |
| Band Support |
Band 71 and additional LTE/5G bands |
| IP Rating |
IP67 (Waterproof) |
| Form Factor |
Low-Profile Wall Mount |
| Applications |
IoT, Automotive, Telematics, Fleet Management |
Frequently Asked Questions
What is a 17-in-1 combination antenna used for?
A 17-in-1 combination antenna like the GuardianX consolidates multiple connectivity functions—GNSS positioning, cellular, and Wi-Fi—into one device. This is ideal for IoT gateways, connected vehicles, and telematics systems where space is limited and reliable multi-band coverage is essential.
Can the MA9917 GuardianX handle outdoor and harsh environments?
Yes. The IP67-rated wall mount antenna is fully waterproof and designed for demanding outdoor deployments. Its heavy-duty enclosure protects against moisture, dust, and extreme weather, making it suitable for automotive, industrial, and remote IoT applications.
What makes Wi-Fi 6 MIMO better than standard Wi-Fi antennas?
Wi-Fi 6 MIMO technology delivers higher data rates, improved efficiency, and better performance in congested environments. The GuardianX's eight Wi-Fi 6 MIMO elements provide superior signal quality and throughput compared to single-element designs, critical for bandwidth-intensive IoT and vehicle applications.
Does the MA9917 support 5G connectivity?
Absolutely. The GuardianX features eight 5G/4G cellular MIMO elements operating across 600MHz to 6000MHz, including Band 71 support. This ensures seamless 5G and LTE fallback connectivity for modern connected vehicle and IoT deployments.
