Tycon ENC-STL-24x24x16 Steel Outdoor Enclosure
The Tycon ENC-STL-24x24x16 steel outdoor enclosure is engineered for mission-critical deployments where electronics face extreme weather, UV exposure, and demanding environmental conditions. This NEMA 4X / IP65 weatherproof enclosure protects sensitive equipment in remote sites, telecom installations, solar farms, and industrial applications where reliability cannot be compromised. Built for harsh climates and heavy-duty use, it delivers robust protection with intelligent thermal management and secure access control.
Key Features
- NEMA 4X / IP65 weatherproof rating with UV-resistant steel construction
- Thermostatically controlled ventilation system with gasket seal protection
- Dual battery shelves supporting up to 400Ah total battery capacity
- 1U 19" rackmount shelf for standard networking and power equipment
- Built-in DIN rails on sides, door, and back for flexible component mounting
- Weatherproof cable feedthroughs for secure external connections
- Lockable latch compatible with standard padlocks for equipment security
- Wall and pole mountable with included hardware for rapid deployment
Technical Specifications
| Specification |
Details |
| Manufacturer |
Tycon Systems |
| Part Number |
ENC-STL-24x24x16 |
| Enclosure Type |
Steel Outdoor Enclosure |
| Dimensions |
24" W x 24" H x 16" D |
| Weather Rating |
NEMA 4X / IP65 |
| Material |
UV-Resistant Steel |
| Battery Capacity |
Up to 400Ah (dual shelves) |
| Rackmount Shelf |
1U 19" standard |
| DIN Rail Locations |
Sides, Door, Back |
| Mounting Options |
Wall and Pole Mount |
| Security |
Lockable Latch with Padlock Support |
| Ventilation |
Thermostatically Controlled |
| Cable Management |
Weatherproof Feedthroughs |
Frequently Asked Questions
What makes this steel outdoor enclosure suitable for harsh environments?
The ENC-STL-24x24x16 combines NEMA 4X / IP65 weatherproof certification with UV-resistant steel construction and gasket seals to protect electronics from rain, dust, extreme temperatures, and solar degradation. Thermostatically controlled ventilation prevents condensation and thermal stress.
How much battery capacity can this outdoor enclosure support?
This weatherproof enclosure features two battery shelves capable of supporting up to 400Ah total battery capacity, making it ideal for backup power systems, renewable energy installations, and off-grid telecommunications sites.
Can I mount networking equipment in this NEMA 4X enclosure?
Yes. The built-in 1U 19" rackmount shelf accommodates standard networking switches, routers, and power distribution units. Combined with DIN rails throughout the enclosure, you can configure flexible layouts for mixed equipment deployments.
What mounting options are available for this steel enclosure?
The ENC-STL-24x24x16 supports both wall and pole mounting configurations. All required mounting hardware is included for quick installation in remote locations or outdoor equipment yards.
