Tycon Power UPS-ST24-50 Outdoor UPS Battery Backup System
The Tycon Power UPS-ST24-50 is a professional-grade outdoor UPS system designed for remote installations, telecom towers, and off-grid applications requiring continuous 24V power. This 24V 50Ah battery backup delivers 600Wh of reliable energy storage with up to 120W output capacity, housed in a rugged steel enclosure built to withstand harsh outdoor environments. Whether you're powering wireless access points, surveillance systems, or remote monitoring equipment, this outdoor UPS provides the dependable backup power your critical infrastructure demands.
Key Features
- 24V 50Ah lithium-ready battery (600Wh total capacity)
- Continuous 24V 100W load output with 120W peak capacity
- Rugged steel enclosure for outdoor durability and weather protection
- 24V 20A PWM charge controller with digital status display
- 20A integrated load control for automated power management
- Ideal for remote telecom, solar, and off-grid backup applications
- Compact design for easy installation in tight spaces
- Low-maintenance operation with reliable long-term performance
Technical Specifications
| Specification |
Details |
| Manufacturer |
TYCON SYSTEMS |
| Part Number |
UPS-ST24-50 |
| Battery Voltage |
24V DC |
| Battery Capacity |
50Ah |
| Total Energy Storage |
600Wh |
| Continuous Output |
24V 100W |
| Peak Output |
24V 120W |
| Charge Controller |
24V 20A PWM with Display |
| Load Control |
20A Integrated Controller |
| Enclosure Material |
Steel (Outdoor-Rated) |
| Application |
Outdoor UPS, Remote Backup Power, Telecom, Solar Integration |
Frequently Asked Questions
What is an outdoor UPS system and why do I need one?
An outdoor UPS is a battery backup system designed to provide continuous power to remote equipment during outages or in off-grid locations. The Tycon Power UPS-ST24-50 is essential for protecting telecom infrastructure, wireless networks, surveillance systems, and solar installations from power interruptions.
How long will the 24V 50Ah battery backup power my equipment?
Runtime depends on your load. With a 100W continuous load, the 600Wh 24V 50Ah battery provides approximately 6 hours of backup power. For lighter loads (50W), runtime extends to 12+ hours. The integrated 20A PWM controller optimizes charging and load management for maximum efficiency.
Can the UPS-ST24-50 work with solar panels?
Yes. The built-in 24V 20A PWM charge controller makes this outdoor UPS ideal for solar integration. It efficiently charges the 50Ah battery from solar arrays and manages load distribution, making it perfect for remote off-grid applications.
Is the steel enclosure weatherproof?
The rugged steel enclosure is outdoor-rated and designed to protect the battery and controller from harsh weather conditions, UV exposure, and temperature extremes. It's engineered for reliable performance in demanding remote environments.
