RemotePro 12/24V 50W MPPT Solar Power System with 340W Solar Array
The RemotePro 340W Series is a complete off-grid power system engineered for remote locations, telecommunications equipment, surveillance systems, and outdoor applications requiring reliable, continuous power. This 12/24V MPPT solar power solution combines a 340W solar array with a 200Ah battery bank and 50W MPPT charge controller to deliver uninterrupted power in areas without grid access. Perfect for mission-critical remote installations, the RemotePro system maximizes solar energy harvest while maintaining consistent voltage output for sensitive equipment.
Key Features
- 50W MPPT charge controller for optimized solar energy conversion
- 340W solar array delivers maximum power generation in variable light conditions
- 200Ah battery storage provides extended runtime and backup power capacity
- Dual voltage support: 12V and 24V configurations for flexible deployment
- Continuous remote power operation without grid dependency
- Weatherproof outdoor-rated enclosure for harsh environments
- Integrated system monitoring and protection circuitry
- Scalable design supports multiple equipment types and power requirements
Technical Specifications
| Specification |
Details |
| Manufacturer |
TYCON SYSTEMS |
| Part Number |
RPL12/24M-200-340 |
| System Type |
Off-Grid Solar Power System |
| Voltage Options |
12V / 24V Selectable |
| Charge Controller |
50W MPPT |
| Solar Array Capacity |
340W |
| Battery Bank |
200Ah Lithium or Lead-Acid Compatible |
| Operating Temperature |
-40°C to +60°C |
| Enclosure Rating |
IP65 Weatherproof |
| Installation |
Pole or Wall Mount |
Frequently Asked Questions
What is an MPPT charge controller and why does the RemotePro use one?
MPPT (Maximum Power Point Tracking) is an advanced charging technology that optimizes the solar array's output by continuously adjusting voltage and current to extract maximum available power. The RemotePro's 50W MPPT controller increases energy harvest efficiency by up to 30% compared to standard PWM controllers, ensuring your 340W solar array delivers peak performance even in partial shade or variable weather conditions.
How long will the 200Ah battery power my remote equipment?
Runtime depends on your equipment's power consumption. For example, a 50W load would run approximately 48 hours on a fully charged 200Ah battery at 12V. The RemotePro's continuous charging from the 340W solar array means the battery recharges during daylight, providing indefinite off-grid operation in most climates. Calculate your specific runtime by dividing battery capacity (200Ah) by your equipment's current draw.
Can I use the RemotePro for telecommunications or surveillance systems?
Yes. The RemotePro 12/24V system is specifically designed for remote power applications including cell towers, microwave repeaters, security cameras, and monitoring stations. Its dual voltage configuration, MPPT efficiency, and large 200Ah battery bank make it ideal for mission-critical equipment requiring 24/7 uptime without grid access.
What maintenance does an off-grid solar power system require?
The RemotePro requires minimal maintenance: periodic inspection of solar panel cleanliness, battery terminal connections, and weatherproof enclosure seals. The MPPT controller automatically manages charging cycles, and the integrated protection circuitry safeguards against overcharge and deep discharge, extending system lifespan to 10+ years with proper care.
