Tycon RemotePro Off-Grid Remote Power System with 170W Solar Panel & MPPT Controller
The Tycon RemotePro RPL12/24M-200-170 is a complete off-grid remote power system engineered for locations without utility electricity. Delivering 40W continuous power output, this integrated solution combines a high-efficiency MPPT solar charge controller, 170W solar panel with mount, and a robust 208Ah battery bank in a large aluminum enclosure. Perfect for powering network equipment, IP cameras, wireless access points, and surveillance systems in remote installations, this system provides reliable 12/24V PoE output for mission-critical deployments.
Key Features
-
40W Continuous Power Output — Stable 12/24V supply for remote electronics and network devices
-
170W Solar Panel with Mount — High-efficiency monocrystalline panel with integrated mounting hardware for optimal sun exposure
-
MPPT Solar Charge Controller — Maximum Power Point Tracking technology maximizes energy harvest and battery charging efficiency
-
208Ah Battery Bank — Large-capacity 12/24V lithium or lead-acid battery for extended off-grid operation and load buffering
-
12/24V PoE Output — Direct Power over Ethernet support for surveillance cameras, wireless access points, and network equipment
-
Large Aluminum Enclosure — Durable weatherproof housing protects all components from environmental elements
-
Dual Voltage Configuration — Selectable 12V or 24V operation for flexible system integration
-
Remote Monitoring Ready — Built-in connectivity for system status and performance tracking
Technical Specifications
| Specification |
Details |
| Manufacturer |
TYCON SYSTEMS |
| Part Number |
RPL12/24M-200-170 |
| System Type |
Off-Grid Remote Power System |
| Continuous Power Output |
40W |
| Solar Panel Capacity |
170W Monocrystalline |
| Battery Capacity |
208Ah (12/24V selectable) |
| Charge Controller |
MPPT (Maximum Power Point Tracking) |
| Output Options |
12/24V PoE, Standard 12/24V DC |
| Enclosure |
Large Aluminum, Weatherproof |
| Mounting |
Solar panel mount included |
| Applications |
Remote surveillance, wireless networks, IP cameras, access points, off-grid sites |
Frequently Asked Questions
What is an off-grid remote power system used for?
An off-grid remote power system provides electricity to locations without utility power access. The Tycon RemotePro is ideal for powering surveillance cameras, wireless access points, and network equipment at remote sites, construction areas, and rural installations where grid power is unavailable or unreliable.
How does the MPPT controller improve solar charging?
The MPPT solar charge controller continuously adjusts the solar panel's operating point to extract maximum available power from the sun. This technology increases charging efficiency by 20-30% compared to standard PWM controllers, enabling faster battery charging and better system performance in variable sunlight conditions.
Can this system power PoE network equipment?
Yes. The RemotePro includes dedicated 12/24V PoE output that directly powers Power over Ethernet devices like IP cameras, wireless access points, and network switches. This eliminates the need for separate PoE injectors and simplifies remote installation.
What battery capacity does the 208Ah system provide?
The 208Ah battery bank stores substantial energy for extended off-grid operation. At 40W continuous draw, this capacity provides multiple days of autonomous operation depending on solar recharge rates and seasonal sunlight availability, making it suitable for mission-critical remote deployments.
