Tycon RemotePro RPPL1224-36-35 Remote Power System
The RemotePro PL Series RPPL1224-36-35 is a complete off-grid remote power system engineered for reliable, continuous operation in locations without grid access. This 8W continuous remote power system combines a 35W solar panel, 36Ah battery bank, and intelligent solar controller to deliver uninterrupted power to wireless access points, IP cameras, and remote network devices. Perfect for rural deployments, tower installations, and outdoor surveillance applications, this system eliminates the need for expensive trenching or generator maintenance while providing 24V 30W passive PoE output for standard network equipment.
Key Features
-
35W Solar Panel with Mount — Optimized for consistent daily charging in remote locations
-
36Ah 12V AGM Battery Bank — Extended runtime and reliable energy storage for continuous operation
-
8A Solar Controller — Intelligent charge management maximizes battery lifespan and system efficiency
-
24V 30W Passive PoE Output — Powers standard network devices without additional power injectors
-
12V 1.5A Auxiliary DC Output — Flexible secondary power for sensors, lights, or monitoring equipment
-
8W Continuous Power Delivery — Stable, regulated output for mission-critical remote installations
-
Weather-Resistant Polycarbonate Enclosure — Durable construction withstands harsh outdoor environments
-
Passive PoE Technology — No active components required; compatible with standard PoE devices
Technical Specifications
| Specification |
Value |
| Manufacturer |
TYCON SYSTEMS |
| Part Number |
RPPL1224-36-35 |
| Solar Panel Output |
35W |
| Battery Capacity |
36Ah 12V AGM |
| Solar Controller Rating |
8A |
| Primary Output (PoE) |
24V 30W Passive PoE |
| Auxiliary Output |
12V 1.5A DC |
| Continuous Power |
8W |
| Enclosure Material |
Polycarbonate (Weather-Resistant) |
| Application |
Off-Grid Remote Power, Wireless Networks, Surveillance |
Frequently Asked Questions
What devices can this remote power system support?
The RemotePro RPPL1224-36-35 is ideal for powering wireless access points, IP cameras, cellular boosters, environmental sensors, and other remote network equipment. The 24V 30W passive PoE output supports standard PoE devices, while the 12V auxiliary output provides flexible power for additional peripherals.
How long will the 36Ah battery provide continuous power?
Runtime depends on load and weather conditions. With the 8W continuous output and 36Ah battery capacity, the system can sustain operation through multiple days of limited sunlight. The intelligent 8A solar controller optimizes daily charging to maintain consistent power availability.
Is this off-grid power system suitable for harsh outdoor environments?
Yes. The weather-resistant polycarbonate enclosure protects all components from rain, UV exposure, and temperature extremes. This outdoor remote power system is engineered for permanent installation in remote locations without shelter.
Can I expand this system with additional solar panels or batteries?
The 8A solar controller and modular design allow for future expansion. Consult Tycon Systems documentation for compatible panel and battery configurations to scale your off-grid power capacity.
