Tycon RemotePro RPSTL24M-100-320 Off-Grid 24V Remote Power System
The Tycon RemotePro RPSTL24M-100-320 is a complete off-grid remote power system engineered for mission-critical field deployments requiring reliable, continuous 24V power. This integrated 24V 100W continuous power solution combines solar generation, intelligent charge management, and robust battery storage in a single weatherproof package. Ideal for remote telecommunications sites, surveillance installations, environmental monitoring stations, and off-grid IoT applications, the RemotePro delivers uninterrupted power in locations where grid connectivity is unavailable or impractical. The system's 320W solar panel, MPPT charge controller, and 104Ah battery bank work seamlessly to maximize energy harvest and minimize downtime.
Key Features
-
100W Continuous Power Output — Reliable 24VDC 10A delivery for sustained remote operations
-
320W Solar Panel — High-efficiency monocrystalline generation for optimal daylight energy capture
-
MPPT Solar Charge Controller — Maximum Power Point Tracking technology maximizes charging efficiency in variable light conditions
-
24V 104Ah Battery Bank — Extended runtime and deep-cycle reliability for multi-day autonomy
-
Steel Outdoor Enclosure — Rugged, weatherproof housing protects components from harsh environmental conditions
-
Integrated System Design — Factory-configured and tested for immediate deployment
-
24VDC 10A Output — Standardized industrial voltage for compatibility with remote equipment
-
Off-Grid Capability — Complete energy independence without utility connection requirements
Technical Specifications
| Specification |
Value |
| Manufacturer |
TYCON SYSTEMS |
| Part Number |
RPSTL24M-100-320 |
| System Voltage |
24VDC |
| Continuous Power Output |
100W |
| Output Current |
10A |
| Solar Panel Capacity |
320W |
| Battery Capacity |
104Ah |
| Battery Type |
24V Lithium or Lead-Acid (configuration dependent) |
| Charge Controller |
MPPT (Maximum Power Point Tracking) |
| Enclosure Material |
Steel |
| Enclosure Rating |
Outdoor-rated, weatherproof |
| Operating Temperature |
-20°C to +60°C (typical) |
| Application |
Remote off-grid power, telecommunications, surveillance, IoT monitoring |
Frequently Asked Questions
What is an off-grid remote power system and how does it work?
An off-grid remote power system operates independently from utility grids, using renewable energy (solar) and battery storage to provide continuous power. The RemotePro's MPPT controller charges the 104Ah battery from the 320W solar panel during daylight, while the battery supplies 100W continuous power to remote equipment 24/7, ensuring uninterrupted operation in isolated locations.
How long will the 24V 104Ah battery provide 100W continuous power?
The 104Ah battery at 24V provides approximately 2,496Wh of energy. At 100W continuous draw, theoretical runtime is roughly 25 hours of autonomy. Actual runtime depends on solar recharge cycles, weather conditions, and battery chemistry. The MPPT controller optimizes daily recharge to maintain consistent availability.
Can the RemotePro RPSTL24M-100-320 handle peak power demands above 100W?
The system is rated for 100W continuous power output. Brief peak loads may be supported depending on battery state and charge controller configuration, but sustained loads above 100W will reduce battery life and system reliability. Consult Tycon documentation for peak load specifications.
Is the steel enclosure suitable for harsh outdoor environments?
Yes, the steel outdoor enclosure is engineered for harsh field conditions, providing protection against weather, UV exposure, and physical damage. Regular maintenance and inspection are recommended for long-term durability in extreme climates.
