Tycon Systems RemotePro RPS12/24-100-170 Remote Solar Power System
The RemotePro 170W Series delivers reliable off-grid power for remote installations where grid connectivity isn't available. This solar power system combines a 170W solar panel with a 100Ah battery to provide continuous 25W output at 12/24V DC, making it ideal for powering surveillance cameras, wireless networking equipment, and communication devices in remote locations. Built for harsh outdoor environments, the RPS12/24-100-170 ensures your critical infrastructure stays powered 24/7 without fuel costs or maintenance.
Key Features
- 170W solar panel for maximum energy capture in remote locations
- 100Ah lithium or lead-acid battery storage for extended runtime
- Dual voltage output: 12V and 24V DC selectable configuration
- 25W continuous power delivery for networking and surveillance devices
- Integrated charge controller with MPPT optimization
- Weatherproof outdoor enclosure rated for extreme conditions
- Low-maintenance design suitable for unattended remote installations
- Scalable system architecture for multi-unit deployments
Technical Specifications
| Specification |
Details |
| Manufacturer |
Tycon Systems |
| Part Number |
RPS12/24-100-170 |
| Solar Panel Capacity |
170W |
| Battery Capacity |
100Ah |
| Output Voltage |
12V/24V DC (selectable) |
| Continuous Power Output |
25W |
| Charge Controller |
MPPT (Maximum Power Point Tracking) |
| Operating Temperature |
-40°C to +60°C |
| Enclosure Rating |
IP65 weatherproof |
| Application |
Remote surveillance, wireless networking, communication systems |
Frequently Asked Questions
What is a remote solar power system used for?
A remote solar power system like the RemotePro 170W provides off-grid electricity for applications where traditional power lines are unavailable or impractical. Common uses include powering surveillance cameras, wireless access points, cellular boosters, and environmental monitoring equipment in rural, mountainous, or marine locations.
How long will the 100Ah battery power my equipment?
Runtime depends on your device's power consumption. With a 25W continuous load, the 100Ah battery at 12V provides approximately 48 hours of operation. The 170W solar panel recharges the battery during daylight hours, enabling indefinite operation in most climates. Actual runtime varies based on weather, latitude, and seasonal sunlight availability.
Can I use this off-grid power system for surveillance cameras?
Yes, the RemotePro RPS12/24-100-170 is specifically designed for surveillance power applications. Its 25W continuous output supports multiple IP cameras, PTZ units, or thermal imaging systems. The dual 12V/24V output accommodates various camera power requirements, and the 100Ah battery ensures 24/7 monitoring even during extended cloudy periods.
Is the RemotePro 170W system suitable for harsh outdoor environments?
Absolutely. The RPS12/24-100-170 features an IP65-rated weatherproof enclosure designed for extreme conditions including salt spray, UV exposure, and temperature extremes from -40°C to +60°C. This makes it ideal for coastal installations, desert deployments, and high-altitude remote sites where equipment durability is critical.
