Tycon Systems UPSPro 100W 600VA Solar-Ready Outdoor UPS System
The Tycon Systems UPSPro UPS12-50-120 is a rugged solar-ready outdoor UPS system engineered for mission-critical applications requiring continuous 12VDC backup power in remote and harsh environments. This 100W 600VA uninterruptible power supply combines a high-capacity 12V 50Ah AGM battery with dual AC input support (120/240VAC), making it ideal for telecom towers, CCTV surveillance systems, remote monitoring stations, and off-grid networking equipment. Whether you're protecting critical infrastructure or powering remote IoT devices, this solar-ready UPS delivers reliable, maintenance-free backup power with expandable solar charging capability.
Key Features
- 100W continuous output with 120W maximum power delivery
- 12V 50Ah sealed lead acid AGM battery (600Wh capacity)
- Dual AC input support: 120/240VAC automatic detection
- 12VDC 20A unregulated output for sensitive equipment
- Solar-ready design with integrated charge controller compatibility
- Maintenance-free valve-regulated sealed battery technology
- Outdoor-rated enclosure for extreme temperature environments
- Compact form factor for tower and pole mounting
Technical Specifications
| Specification |
Details |
| Manufacturer |
TYCON SYSTEMS |
| Part Number |
UPS12-50-120 |
| Output Power |
100W continuous / 120W maximum |
| Output Voltage |
12VDC unregulated |
| Output Current |
20A maximum |
| Input Voltage |
120/240VAC (auto-sensing) |
| Battery Type |
12V 50Ah sealed lead acid AGM |
| Battery Capacity |
600Wh |
| Backup Runtime |
Varies by load (up to 6 hours at 100W) |
| Solar Ready |
Yes - compatible with solar charge controllers |
| Operating Temperature |
-20°C to +60°C |
| Enclosure Rating |
Outdoor-rated, weatherproof |
Frequently Asked Questions
What is a solar-ready outdoor UPS system used for?
A solar-ready outdoor UPS system like the UPSPro provides uninterrupted 12VDC power to remote equipment such as cellular base stations, CCTV cameras, weather stations, and network switches. The solar-ready design allows you to integrate solar panels for continuous charging, eliminating the need for grid power in off-grid locations.
How long will the 12V 50Ah battery backup power my equipment?
Runtime depends on your load. At full 100W output, the 600VA UPS system provides approximately 6 hours of backup power. For lighter loads (e.g., 50W), runtime extends to 12+ hours. The sealed AGM battery requires no maintenance and delivers consistent performance in outdoor conditions.
Can I expand the battery capacity or add solar panels?
Yes. The UPSPro is designed for modular expansion. You can add external 12V 50Ah AGM batteries in parallel to increase capacity, and the integrated charge controller supports solar panel integration for continuous renewable charging in outdoor environments.
What makes this UPS suitable for outdoor deployment?
The Tycon Systems outdoor UPS features a weatherproof enclosure, valve-regulated sealed battery technology (no acid leakage), and wide operating temperature range (-20°C to +60°C). These design elements ensure reliable performance in rain, snow, extreme heat, and remote locations without maintenance.
