WyreStorm 18Gbps 4K HDR HDBaseT Extender with HDCP 2.2 and 2-way PoH
HDMI 2.0 MAXED OUT
Knowing the speed at which technology moves, at WyreStorm we're always looking ahead. That's why we've implemented our VLC chipset (Visualy Lossless Compression) into this model meaning it's ready for the next shift in content technology: 4K 60Hz 4:4:4 HDR.
HDCP 2.2 COMPLIANT
The latest 4K UHD content arriving via satellite, cable, disc or stream is all heavily encrypted. Being part of the H2 product family, the EX-70-H2 supports the multi-point distribution of this content over HDBaseT™.
SIGNAL RE-CLOCKING
Installers shouldn't experience problems because of source equipment they have no control over. That's why all extenders in the WyreStorm H2 family automatically "re-clock" the source signal, overcoming clock-stretching issues found in certain source devices.
FLEXIBLE INSTALL OPTIONS WITH 2-WAY POH
No 2 installs are the same; that's why we've enabled all of the H2 extender line up to be powered from either the TX or RX, meaning maximum flexibility on-site without hunting for a mains outlet.
- Dynamic visually lossless compression enables extension of up to 4K/60 4:4:4 or HDR 60Hz content over HDBaseT™
- HDBaseT™ Class A transmission of 4K up to 70m/230ft and 1080p up to 100m/328ft
- Compatible with the latest HDR standards, including HDR-10+, HLG content, with support for Dolby Vision™ up to 30Hz
- Supports all VESA resolutions within the HDMI 2.0 specification
- Advanced re-clocking chipset increases compatibility with new 4K UHD source devices
- Bidirectional IR and RS-232 pass-through
- Supports CEC communication between devices
- Slimline 21mm/0.83in chassis for easier, more convenient installation behind displays
- 2-way PoH (Power over HDBaseT™) enabling either transmitter or receiver to be remotely powered by the other unit.
- Supports 2ch PCM and 7.1 multichannel audio up to DTS:X and Dolby Atmos
Product Type: Video Extender Transmitter/Receiver
Environmentally Friendly: Yes
Environmental Certification: RoHS
Transmitter Height: 0.60"
Transmitter Width: 5.37"
Transmitter Depth: 2.92"
Receiver Height: 0.60"
Receiver Width: 5.37"
Receiver Depth: 2.92"
Transmitter Weight (Approximate): 8.47 oz
Receiver Weight (Approximate): 8.47 oz
Brand Name: WyreStorm
Form Factor: Rack-mountable
Manufacturer: WyreStorm
Product Model: EX-70-H2
Product Name: 18Gbps 4K HDR HDBaseT Extender with HDCP 2.2 and 2-way PoH
Manufacturer Part Number: EX-70-H2
Manufacturer Website Address: http://www.wyrestorm.com
Limited Warranty: 5 Year
