ZPE Nodegrid Gate SR - Serial & Ethernet Management Platform
The ZPE Nodegrid Gate SR is a powerful branch solutions platform engineered for remote IT management and out-of-band access. Built on a multi-core Intel x86_64 CPU with 64-bit Nodegrid Linux OS, this serial management device delivers converged infrastructure and flexible networking for distributed IT environments. With 8 RJ45 serial ports and 11 Ethernet ports (5 GbE, 4 PoE+, 2 SFP+), the Gate SR provides resilient connectivity for remote branch management, data center operations, and mission-critical deployments requiring secure, redundant access.
Key Features
-
8 RJ45 Serial Ports (Rolled) — Direct serial console access for legacy and modern equipment management
-
11 Ethernet Ports — 5 Gigabit Ethernet + 4 PoE+ ports + 2 SFP+ uplink interfaces for flexible network topology
-
Multi-Core Intel x86_64 CPU — High-performance processing for concurrent management sessions and network operations
-
8GB DDR4 DRAM — Expandable memory for demanding branch management workloads
-
32GB Hardware-Encrypted SSD — Secure storage with built-in encryption for sensitive configuration data
-
Dual 36–75 VDC Redundant Power Input — Optional AC adapter support for resilient power delivery in remote locations
-
64-Bit Nodegrid Linux OS — Purpose-built operating system for network management and out-of-band access
-
PoE+ Power Delivery — Power remote devices directly from the Gate SR platform
Technical Specifications
| Component |
Specification |
| Manufacturer |
ZPE SYSTEMS INC |
| Part Number |
ZPE-GSR-48-BASE |
| Product Name |
Gate SR - 8 RJ45 Serial Ports (Rolled) - 11 Ethernet Ports (5x GbE - 4x PoE+ - 2x SFP+) - 4-Core CPU - 8GB DDR4 - 32GB Hardware Encrypted SSD |
| Processor |
Multi-Core Intel x86_64 CPU (4-Core) |
| Memory |
8GB DDR4 DRAM (expandable to 32GB) |
| Storage |
32GB Hardware-Encrypted SSD |
| Serial Interfaces |
8 RJ45 Serial Ports (Rolled) |
| Ethernet Interfaces |
11 Total: 5x Gigabit Ethernet + 4x PoE+ + 2x SFP+ |
| Power Input |
Dual 36–75 VDC Redundant (Optional AC Adapter) |
| Operating System |
64-Bit Nodegrid Linux OS |
Frequently Asked Questions
What is the ZPE Nodegrid Gate SR used for?
The Nodegrid Gate SR is a branch solutions platform designed for remote branch management, out-of-band access, and converged infrastructure in distributed IT environments. It provides secure serial console access and flexible Ethernet connectivity for managing equipment across remote locations.
How many serial ports does the Gate SR have?
The Gate SR features 8 RJ45 serial ports (rolled), enabling direct console access to multiple devices simultaneously for comprehensive out-of-band management.
Can the Gate SR power remote devices?
Yes. The Gate SR includes 4 PoE+ ports that deliver power to compatible network devices, reducing the need for separate power infrastructure at remote branch locations.
What are the power requirements for the Nodegrid Gate SR?
The Gate SR supports dual 36–75 VDC redundant power input for resilient deployments, with an optional AC power adapter available for alternative power environments.
